Marshall OR-XDI-XLR 3GSDI to HDMI Cross Converter with 4pin XLR Adapter

ITEM #: MAR-OR-XDI-XLR MFG #: OR-XDI-XLR

Primary Image

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the MAR-OR-XDI-XLR

OR-XDI-XLR - Overview

The ORCHID OR-XDI is a rugged and portable battery-powered HDMI to 3G-SDI / 3G-SDI to HDMI cross converter. It allows an HDMI video signal to be converted from HDMI to 3G-SDI (with audio) to feed two other monitor sources on location. It can also be used to take the 3G-SDI output from production cameras to feed both the HDMI input of an external monitor while simultaneously feeding the 3G-SDI to other locations and equipment. The OR-XDI can be powered using a consumer-type 12V EIA power adapter, optional 4-pin XLR, or by using a wide variety of Marshall small battery mounts. This is the perfect tool for any director, camera operator, or production video village.

  • Features:

    • Simultaneously outputs two 3G-SDI signals and one HDMI signal at the same time
    • HDMI-to-SDI / SDI-to-HDMI conversion including Audio
    • Automatic input port switching
    • Automatic video format detection
    • Built-in SD format interlacer for DSLR while recording (480p to 480i conversion)
    • Status LEDs indicate link speed and health
    • Consumes 50% less energy and operates twice as long as competing converters
    • 8-position piano switch (input port selection, power save)
    • Built-in Color Bar Test Pattern Generator
    • USB service port for future upgrades
    • Rugged metal alloy case
    • Dual size mounting holes (1/4-20)
    • EIA 12VDC External Power Jack
    • 4-pin XLR 12VDC Input
    • 3.91" W x 2.28" D x 1.38" H Weighs only 7.6 ounces (without battery)
