PreSonus StudioLive RML16 AI 16-Channel Rack-Mount Digital Mixer with 16 Remote XMAX Preamps - Mic & Line Inputs

ITEM #: PRE-SL-RML16-AI MFG #: STUDIOLIVE RML16 AI

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the PRE-SL-RML16-AI

STUDIOLIVE RML16 AI - Overview

Equally at home in houses of worship, schools, broadcast facilities, live venues, touring rigs, and recording studios, the PreSonus StudioLive RML16AI rack-mount Active Integration digital mixer is a versatile and flexible solution for live sound and recording. These versatile 25-bus mixers offer 8 mic inputs, 8 combo mic/line inputs, and 16 digital inputs via FireWire, AVB, or Dante, for a total of 32 input channels, expandable up to 64. StudioLive RML16AI mixers are flawlessly integrated with state-of-the-art software and boast an integrated multitrack recording interface, advanced AVB or Dante networking, and multiple control options. Yet they're easy to use, with a workflow that will let you focus on mixing, without being distracted by the technology.

PreSonus StudioLive RML-series mixers are tightly integrated with an entire suite of state-of-the-art software. Mix wirelessly or over a wired network from anywhere using UC Surface touch-control software for Mac, Windows, and iPad. Remote control the mixer's recallable XMAX preamps and Fat Channel processing with Studio One Artist for low-latency recording with effects. Musicians control their monitor mixes onstage with QMix-AI for iPhone/iPod touch. Completely automate virtual soundchecks and record shows at up to 96 kHz with Capture. Tune your system to the room and watch for problems in your mix with UC Surface's integrated Smaart wizards, RTA, and spectrograph. Save mixer scenes with your live recordings in Capture and edit both in Studio One Artist. StudioLive RML-series mixers and software work together to form a cohesive ecosystem that helps you achieve your creative vision.

Now Includes Free Studio Magic Plug-in Suite
This suite of plug-ins brings extended sonic functionality into Studio One. Cherry-picked from the first names in virtual instruments and effects, each one brings a different flavor of practical magic to your songs. These plug-ins aren't gimmicky one-trick ponies - these are real-deal workhorses that you'll find yourself relying on for countless mixes.

  • Features:

    • Inputs and Outputs
    • 8 locking XLR mic inputs and 8 combo locking XLR mic-1/4" TRS line inputs, each with:
    • Recallable XMAX Class A analog mic preamps
    • +48V phantom power

    • Stereo tape input (RCA jacks)
    • 8 XLR line-level Mix outputs
    • Four 300 ms alignment delays on the last four Mix outputs
    • 1 DB25 jack mirrors 8 line-level Mix outputs
    • 3 XLR main outputs (left, right, mono/center) with analog trim pots
    • S/PDIF digital output on removable option card
    • Headphone output with volume knob and selectable source
    • 1x1 MIDI I/O (for future implementation)

    • Channels and Buses
    • 32 internal channels
    • 25 mix buses
    • 16 aux mix buses
    • 3 main mix buses (left, right, mono/center)
    • Stereo solo bus
    • 4 internal FX buses (2 reverb, 2 delay)
    • Fully integrated, continuously bidirectional, 52-in/34-out, FireWire 800 direct recording interface (24-bit, 44.1/48/88.2/96 kHz)

    • UC Surface Live Mixing and Control Software
    • Designed specifically for live sound mixing
    • Multiplatform support for Mac, Windows, and iPad
    • Windows 8/10 multi-touch-compatible for large touchscreen mixing
    • Flexible and expandable computing options: Use a laptop with or without a touchscreen, an iPad, or any combination

    • Other Actively Integrated Software
    • Capture one-click recording software with true virtual soundcheck (Mac/Windows)
    • Studio One Artist full-featured digital audio workstation software (Mac/Windows)
    • QMix-AI wireless monitor-mix control from an iPhone/iPod touch

    • Networking Connections
    • 2 FireWire S800 ports and 1 Ethernet control port with AVB Networking on removable option card. FireWire ports fully compatible with Apple Thunderbolt-to-FireWire adapter.
    • SL-Dante-Mix option card available separately
    • Use AVB to cascade two RM/RML-series mixers to create a larger system (up to 64 channels) or connect the RML mixer to a StudioLive AI-series front-of-house console


  • Specifications:

    • Mac
    • Mac OS X 10.8 64-bit or later
    • Intel Core 2 Duo processor (Intel Core i3 or faster recommended)
    • 4 GB RAM (8 GB or more recommended)

    • Windows
    • Windows 7 x64/x86 SP1, Windows 8 x64/x86, Windows 10 x64/x86
    • Intel Core 2 Duo processor (Intel Core i3 or faster recommended)
    • 4 GB RAM (8 GB or more recommended)

    • Microphone Preamp
    • Input Type: 8 locking XLR Female, balanced; 8 combo locking XLR mic-1/4" TRS line
    • Frequency Response to Direct Output (at unity gain): 20-40 kHz, +/-0.5 dBu
    • Frequency Response to Main Output (at unity gain): 20-20 kHz, +/-0.5 dBu
    • Input Impedance: 1 kΩ
    • THD to Main Output (1 kHz at unity gain): 0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
    • S/N Ratio to Main Output (Ref = +4 dB, 20 kHz BW, unity gain, A-wtd): 94 dB
    • Common Mode Rejection Ratio (1 kHz at unity gain): 65 dB
    • Gain Control Range (+/-1 dB): 0 dB to +65 dB
    • Maximum Input Level (unity gain): +12 dBu
    • Phantom Power (+/-2 VDC): 48 VDC, switchable per channel

    • Line Inputs
    • Type: 1/4" TRS Female (via Combo), Balanced
    • Maximum Input Level (min. gain, 1 [email protected]% THD+N): + 18 dBu, +/-0.5 dB
    • Frequency Response (A-D): 20 Hz to 20 kHz, +/-0.2 dB
    • Dynamic Range (min. gain, A-wtd): > 114 dB
    • Dynamic Range (mid. gain, unwtd): > 105 dB
    • THD+N (1 kHz, -1 dBFS, A-wtd): < 0.005%
    • Input Impedance: 10 kΩ

    • Tape Inputs
    • Type: RCA Female, unbalanced (stereo pair)
    • Maximum Input Level: +12 dBu

    • Main Outputs
    • Type: XLR Male, balanced
    • Rated Output Level: +24 dBu
    • Output Impedance: 100Ω

    • Mix Outputs
    • Type: XLR Male, balanced
    • Rated Output Level: +24 dBu
    • Output Impedance: 100Ω

    • Headphone Output
    • Type: 1/4" TRS Female, active stereo
    • Maximum Output: 100 mW/ch. @ 60Ω load
    • Frequency Response: 20 Hz - 20 kHz (+/- 0.5 dB)
    • THD+N: 0.01%, 1 kHz, max gain, 20 Hz BW, unwtd
    • S/N Ratio: 96 dB, 1 kHz, max gain, 20 Hz BW, unwtd

    • Power Connector: IEC
    • Input-Voltage Range: 90 to 240 VAC
    • Power Requirements (continuous): 200W
    • Recommended Ambient Operating Temperature: 0° to 40° Celsius / 32° to 104° Fahrenheit

    • Height: 5.25" (13.34 cm)
    • Width: 19" (48.26 cm)
    • Depth: 10.5" (26.67 cm)
    • Weight: 19 lbs. (8.62 kg)
    • 3U rack-mount steel chassis


  • GTIN:

    0673454004759
