Atomos ATOMNJPB01 Ninja Phone Video Co-Processor Base Compatible with iPhone 15 Pro & Pro Max - HDMI to USB-C

ITEM #: ATO-ATOMNJPB01 MFG #: ATOMNJPB01

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$399.00

Availability: In Stock
iAvailability Description Popup


ATOMNJPB01 - Overview

Now your phone can be a Ninja too!

Ninja your iPhone 15 Pro or Pro Max into a 1600nit, 10-bit, 2,000,000:1 contrast ratio, 460ppi, HDR OLED, ProRes monitor-recorder for any pro HDMI camera with the Atomos Ninja Phone.

The Ultimate iPhone Accessory
The iPhone is a technological masterpiece, with its amazing Retina monitor and cutting-edge, Wi-Fi 6E and 5G connectivity. But how do you connect your pro camera? With a Ninja Phone! Attach the Ninja Phone to your iPhone 15 Pro or Pro Max, plug in an HDMI-equipped camera, and you've got the best display on the planet with fast, low-latency connectivity and recording capabilities. The device provides a secure mount to attach your iPhone 15 Pro or Pro Max, and enables the locking USB-C connector.

Record 10-bit ProRes From Any HDMI Camera
Ninja Phone is the only way to connect professional cameras with HDMI to an iPhone 15 Pro or Pro Max and record directly into ProRes - the absolute standard for professional video production and post production.

Stream via 5G or Wi-Fi 6E to Social Platforms
You won't find a more compact set-up packed with the latest technology for streaming professional-grade video directly from your camera. Provides pristine 10-bit, H.265 encoding, Wi-Fi 6E, and low-latency 5G for the ultimate in mobile live streaming.

Dual Record 10-bit ProRes and H.265 for Camera to Cloud
Ninja Phone is your gateway to hyper-efficient cloud production workflows. You can choose the way you work: record ProRes master files and H.265 proxies for full, cinematic quality, or encode 10-bit H.265 only from the Ninja Phone for the simplest, fastest workflows that are production quality and perfect for sending direct to social channels. The choice of 10-bit ProRes and/or H.265 is yours.

Super Light, Super Silent
The Ninja Phone is designed on AtomIC 5, the next generation of Atomos silicon that allows for low power, silent operation while encoding 10-bit ProRes and H.265 with exceptional USB-C connectivity. Drawing just 2.4W in full flight, the Ninja Phone combined with the iPhone 15 Pro or Pro Max is silent in operation while performing complex video processing tasks. The powerful IC allows for a super lightweight footprint that complements the iPhone 15 Pro and Pro max's titanium construction.

Please Note: Power is delivered using NP series batteries, a battery eliminator ( both sold separately), or the USB-C 5V/3A input.

  • Features:

    • Connect any HDMI-equipped Mirrorless or Cinema camera to the technology powerhouse that is the iPhone 15 Pro/Max
    • No compromise on quality: capture straight into industry-standard Apple ProRes
    • Work collaboratively with colleagues using hyper-efficient camera to cloud workflows
    • Use the iPhone 15 Pro/Max as the best-ever OLED viewfinder
    • Take perfect shots with Ninja Phone's best-in-class monitoring tools

  • Specifications:

    • Video
    • Video Input Format: 1080p 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98fps, 720p 60 / 59.94 / 50fps
    • Video CODEC: ProRes HQ / ProRes 422 / ProRes LT / ProRes Proxy / H.265 Main 10 / H.265 8b / H.264 8b
    • Video Input Port: HDMI-A
    • Video Output Port: USB 3.1 Gen1, ProRes HQ / ProRes 422 / ProRes LT / ProRes Proxy / H.265 Main 10 / H.265 8b / H.264 8b, 1080p 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98fps, 720p 60 / 59.94 / 50fps

      Audio
    • HDMI: 2 Channel 48KHz PCM
    • USB-C Mic: Matches Microphone Sample Rate. Locks Audio to Video.

      Power
    • USB Power In: USB-C 5V 3A - Ninja Phone charges phone and accessories when attached
    • Accessory Port: USB-C 5V/1A + USB 3.0 Data
    • Battery Compatibility: NP-F550 / F750 / F970 - Ninja Phone charges phone and accessories when attached. 2.4W (without charging iPhone), 4W (with iPhone 15 Pro)
    • Power Consumption: 10W (with iPad Air Gen5)
    • Operating Environment Temperature: 0°~40°C

      Dimensions
    • Height: 3.86" / 98.2mm
    • Width: 3.36" / 85.4mm
    • Depth: 0.68" / 17.4mm

      Weights
    • Ninja Phone: 0.2lbs / 94g / 3.3 ounces
    • iPhone 15 Pro: 0.41lbs / 187g / 6.6 ounces
    • iPhone 15 Pro Max: 0.48lbs / 221g / 7.81 ounces

      Silicon
    • Chip: AtomIC 5

      iPhone Monitor Specs
    • Super Retina XDR display
    • 6.7-inch (diagonal) all-screen OLED display
    • 2796-by-1290-pixel resolution at 460 ppi
    • Dynamic Island
    • Always-On display
    • ProMotion technology with adaptive refresh rates up to 120Hz
    • HDR display
    • True Tone
    • Wide color (P3)
    • Haptic Touch
    • 2,000,000:1 contrast ratio (typical)
    • 1000 nits max brightness (typical); 1600 nits peak brightness (HDR); 2000 nits peak brightness (outdoor)
    • Fingerprint-resistant oleophobic coating
    • Support for display of multiple languages and characters simultaneously

      Screen Weather Proofing
    • Phone Splash, Water, and Dust Resistant
    • Rated IP68 (maximum depth of 6 meters up to 30 minutes) under IEC standard 60529

      Video recording w/Ninja Phone
    • Video formats recorded: HEVC, H.264, and ProRes
    • 1080p HD video recording at 25 fps, 30 fps, or 60 fps
    • 720p HD video recording at 30 fps
    • Cinematic mode
    • HDR video recording with Dolby Vision
    • ProRes video recording up to HDp60 Internal
    • Log video recording
    • Academy Color Encoding System
    • Cinematic video stabilization (4K, 1080p, and 720p)

      Connectivity
    • 5G (sub-6 GHz and mmWave) with 4x4 MIMO
    • Gigabit LTE with 4x4 MIMO and LAA
    • Wi-Fi 6E (802.11ax) with 2x2 MIMO
    • Bluetooth 5.3

  • Item Includes:

    • 1x Atomos ATOMNJPB01 Ninja Phone Co-Processor for iPhone 15 Pro/Pro Max

  • GTIN:

    0814164022972
