Belden FTBLB900FS01 FX Fusion Splice-On Connector OS2 AB2

ITEM #: BL-FTBLB900FS01 MFG #: FTBLB900FS01

Primary Image
Belden
Free Shipping with $49 Minimum Order

List Price:

$15.60

Our Price:

$14.34

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

FTBLB900FS01 - Overview

The FTBLB900FS01
 is an FX fusion OS2 A-B2 LC-APCSX900 Fusion splice-on connector in green. This unit can be used for Field-termination of fiber optic cables within Patch Panels, Distribution Frames, Workstation Outlets for FTTD (Fiber to the Desk), drops for FTTH (Fiber to the home) and MDU (Multiple Dwelling Units).

  • Features:

    • FX Fusion Splice-On Connector
    • A2/B2
    • LC/APC Simplex
    • 900µm
    • Tight Buffer
    • Green Housing


  • Specifications:

    • Maximum Insertion Loss: 0.3 dB
    • Minimum Reflectance: -65 dB
    • Minimum Reflectance @ 1550nm: -65 dB
    • Termination Style: Splice-On
    • Interconnection Compatibility: FOCIS compliant with latest revision of TIA-604-10 (LC)
    • Durabilities@Termination1: 500 Insertions
    • Cable Retention, Straight Pull: 5.1 kg
    • Cable retention, 90 degree pull: 0.2 kg


  • GTIN:

    0611589217255
