Bose MA12EX 150-Watt Loudspeaker - White

ITEM #: BOSE-MA12EX-WE MFG #: 317302-0200

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the BOSE-MA12EX-WE

317302-0200 - Overview

Articulated Array speaker configuration provides wider 160° horizontal coverage and weather-resistant components allow use in outdoor applications. Designed to provide outstanding vocal intelligibility in acoustically demanding spaces. Slim column enclosure blends with almost any décor.

For indoor and outdoor applications.

  • Specifications:

    • Frequency Response (+/-3 dB): 75 Hz - 13 kHz
    • Frequency Range (-10 dB): 58 Hz - 16 kHz
    • Nominal Dispersion: 160° H x 20° V
    • Long-Term Power Handling: 150 W (600 W peak)
    • Sensitivity (SPL / 1 W @ 1 m): 87 dB SPL
    • Maximum SPL @ 1 m: 109 dB SPL (115 dB SPL peak)
    • Nominal Impedance: 8 Ω
    • Enclosure: Extruded-aluminum sidewalls with zinc-plated steel top and bottom endcaps, all powder coated
    • Environmental: Outdoor per IEC 529 IPX5
    • Connectors: Two (2) parallel-wired NL4 Neutrik Speakon connectors
    • Two (2) two-conductor barrier strips
    • Suspension / Mounting: Six (6) x M6 threaded inserts (back)
    • Dimensions: 38.8" H x 4.1" W x 5.5" D (985 mm x 104 mm x 139 mm)
    • Net Weight: 21 lb (9.4 kg)
    • Color: White

  • GTIN:

    0017817500623
