ESE ES 192UE Master Clock Line Frequency Referenced (6-Digit 12 Hour) - Desktop with Option P - 19 Inch Rack Mount

ITEM #: ESE-ES192UE-P MFG #: ES 192UE OPTION P

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$325.00

Our Price:

$308.95

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


ES 192UE OPTION P - Overview

The ESE ES-192UE (12 hour) is a low-cost Master Clock for applications not requiring GPS or temperature controlled stability. Like the LX-192UE, the ES-192UE uses the AC line-frequency as a time reference or, optionally, a quartz crystal timebase may be specified. Time & Date data are output to Slave displays via the TC90™ Time Code output. This Unit comes with Option "p" which includes the 1.75" Rackmount enclosure.

  • Features:

    • .56" Yellow LED Display
    • 12 hour (ES-192UE) or 24 hour (ES-194UE) display
    • Date Function
    • ESE Time Code output (TC90™)
    • 1 PPS (pulse-per-second) output
    • External Time Sync input (corrects error up to 1/2 second)
    • Optional relay-contact closure output on the Hour or Hour & Half Hour
    • Optional 1.75" Rackmount enclosure (option "P")
    • Optional 4-hour Battery Backup (option "P" only)
    • 220-240 VAC (110-120 VAC is standard) & UL options available

  • Specifications:

    • Electrical: 117 VAC, 50/60 Hz
    • Power: 8 Watts Maximum
    • Desk Mount (ES-), 8" W x 2.8" H x 6" D
    • Displays: Six Digits, Yellow LED, .56" High
    • Accuracy: Dependent upon Line Frequency
    • Outputs: 1 PPS: TTL, 80/20% Duty Cycle
    • ESE Time Code (TC90): drives 100 Slaves @ 4000’
    • Options: P

  • Item Includes:

    • 1.75" Rackmount enclosure
