Laird Belden 1505F RG59 Flexible F Male to F Male Digital Coax Cable - 10 Foot

ITEM #: F1505F-10-BK MFG #: F1505F-10-BK

Primary Image
Laird Digital Cinema
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$39.95

Our Price:

$34.95

Add to Wish ListLeasing Options
Availability: 2+ Weeks.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

F1505F-10-BK - Overview

Super flexible RF coaxial cables utilizing Belden 1505F precision high definition cable. These cables are well suited for all analog, digital and HD-SDI transmission. The flexibility of the 1505F delivers a superb bend radius for installs in tight spaces because of the braided center conductor.

  • Features:

    • Belden 1505F Cable

    • Canare FP-C4F F Connector
    • SMPTE ST-2081 6G-SDI compliant


  • Specifications:

    • Belden 1505F RG59/21 SDI Coaxial Cable:
    • RG Type: 59
    • Conductor AWG: 22
    • Outer Jacket Material: PVC - Polyvinyl Chloride
    • Overall Cable Diameter (Nominal): 0.242 in (6.15 mm)
    • Bend Radius Install. Min.: 2.4 in
    • Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
    • Flammability / Reaction to Fire: UL1685 UL Loading
    • Non-UL Temp Rating: 75°C
    • UL Temp Rating: 60°C
    • Operating Temp Range: -35°C To +75°C
    • NEC/CEC Compliance: CM


  • Warranty:

    • 1 Year
