IDX A-VMICRO2 2 Channel Hot Swap V-Mount Adapter Plate w/ 2 x D-Taps and USB-C

A-VMICRO2 - Overview

• Features:

  • The A-VMicro2 is a hot swap adapter that can accommodate two IDX Imicro batteries
  • When two batteries are attached, it discharges in a sequence and automatically switches before the first battery is empty
  • Fitted with 2 D-taps and a USB-C output
  • Capable of fitting to IDX chargers


• Specifications:

  • Output Connectors: (2) D-Tap, (1) USB-C
  • D-Tap: Battery through voltage, 80W max
  • USB-C: DC 5V / 2.3A max
  • Compatibility: IDX Imicro Battery
  • Battery Connection Terminal Rating: 154W max (16.8V/ 9.2A~11V/14A)
  • Main Connector Rating: 154W max (16.8V/ 9.2A~11V/14A)
  • Ambient Temperature: Charge: 0C~40C (10C~30C recommended)
  • Discharge: -20C~45C (10C~40C recommended)
  • Dimensions: 3.86(W) x 5.55(H) x 1.18(D) inches
  • Weight: 0.61 lbs approx.


• Item Includes:

  • 1x IDX A-VMICRO2 2 Channel Hot Swap V-Mount Adapter Plate
  • 4x M3 x 10 Double SEMS screws
