E-Image EK60AAM 2 Stage Aluminum Video Tripod Kit with 75mm Bowl & 17.6 Pounds Payload

ITEM #: IKAN-EK60AAM MFG #: EK60AAM

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$319.99

Our Price:

$287.67

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


EK60AAM - Overview

The E-Image EK60AAM Fluid Drag Video Head and Tripod is a video head and dual-stage tripod leg system designed for video cameras and rigs weighing up to 17.6 pounds. The system consists of the EH60 fluid drag head, the AT7402A aluminum tripod legs with fixed mid-level spreader, one HD7060 adjustable panhandle, and a soft bag for carrying the system. The head has fixed pan and tilt fluid drag for smooth camera moves, and a spring-loaded counterbalance system adjustable in three steps

The included sliding balance plate attaches to your camera with either of the included 1/4"-20 or 3/8"-16 camera tie-down screws. It then slides into the head’s top plate, quickly and securely attaching your camera to the tripod. You can adjust the balance of the camera on the tripod head by sliding the baseplate forward or backward. The sliding balance plate system features a safety release to help prevent the sliding baseplate from accidentally sliding out of the tripod head.

  • Features:

    • Fluid Head
    • Fluid Drag:
      Tilt: Fixed
      Pan: Fixed
    • Spring-Loaded/Three-Stepped Counterbalance:
      0: 0Lbs (0kg)
      1: 6.6Lbs (3kg)
      2: 13.2Lbs (6kg)
    • 75mm Claw ball for fast leveling
    • Bubble level
    • 90° Tilt down—the camera can point straight down
    • 45° Tilt up
    • 360° Panning
    • Mounting rosettes on the left and right sides

      Legs
    • Built-in fixed spreader
    • Working height range of 31 to 63"
    • Rotary clamp leg locks
    • Foot spikes
    • Removable anti-slip pads/foot spike protectors
    • Integrated leg wrap bungee and clip

  • Specifications:

    • Bowl Size: 75 mm Ball base
    • Bubble Level: Yes, non-illuminated
    • Build Material: Anodized aluminum alloy
    • Collapsed Length: Including Head: 32.5" (82.6cm)
    • Counterbalance System: Spring-loaded
    • Fixture Weight: 11Lbs(4.9kg)
    • Height Range:
      Maximum: 63" (160cm)
      Minimum: 31" (79cm)
    • Including Head: 32.5" (82.6cm)
    • Leg Lock Type: Rotary clamp
    • Leg Stage Sections: Two-stage
    • Mounting Plate: Sliding - 4.7 x 1.9 x 0.4" (120 x 49 x 10.5mm)
    • Mounting Points: Camera mounting screw: 1/4"-20 3/8"-16
    • Pan Drag Settings: Fixed fluid
    • Payload: Overall: 17.6Lbs (8kg)
    • Range:
      Counterbalance Range: 6.6 to 17.6Lbs (3 to 8kg) Three steps (0, 1, 2)
      Pan Range: 360°
    • Rosette: Pan Handle Rosettes: 2x Rosettes (one each L/R)
    • Spiked Retractable Feet: Non-retractable spikes with removable spike protectors/anti-slip pads
    • Spreader Type: Mid-Level (NON-removable/adjustable)
    • Tilt Drag: Fixed fluid
    • Tilt Lock: Yes
    • Tilt Range: +90 to -45°
    • Shipping Weight: 18.5Lbs
    • Shipping Dimensions: 37 x 9 x 9"

  • Item Includes:

    • 1x E-Image EK60AAM Fluid Drag Video Head and Tripod
    • 1x Quick Release Plate
    • 1x 1/4"-20 Camera Screw
    • 1x 3/8"-16 Camera Screw
    • 1x Pan Handle
    • 1x Travel Soft Case

  • GTIN:

    0610708234456
