E-Image GH03F Flat Base Pro Fluid Video Head 11 lbs max

ITEM #: IKAN-GH03F MFG #: GH03F

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$139.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


GH03F - Overview

The GH03F Flat Base Pro Fluid Video Head is an affordable tool for tripods sliders, jib arms or anywhere you need smooth cinematic control for camcorders, micro 4/3 and DSLR cameras up to 11lbs. The sturdy all metal head employs adjustable friction torque plates to increase drag to match your cameras weight and offer fluid pans and tilts. Unlike other quick release systems which require the plate to slide in from the rear of the head, the Easy-Lock Base Plate System allows you to attach the camera plate from the top . Machined on the left side of the head a 1/4”-20 socket allows you to mount monitors, drives, and accessories off of the camera.

  • Features:

    • Payload Range 11 lbs
    • Flat Base with 3/8" Thread
    • Variable grades of drag
    • Fixed Counter Balance
    • 1/4" 20 Threaded Accessory Socket for Monitor Arm
    • Seperate Pan/ Tilt Locks
    • Easy-Lock Camera Plate System
    • Sliding Base Plate with Safety Lock and Retractable Registration Pin
    • Spirit Level
    • Dual Sided Pan/Tilt arm Rosettes (one included)
    • All Metal Construction

  • Specifications:

    • Bowl Size: 75mm Flat Head
    • Bubble Level: Yes
    • Camera Plate Size: 120 x 45 x 11mm
    • Camera Plate System: Sliding Base Plate with Safety Locks
    • Counterbalance Settings: Fixed
    • Counterbalance System: Fixed Fluid
    • Head Load Capacity: 11lbs - 5kg
    • Pan Handle Style: Fixed length 355mm
    • Payload: 11lbs - 5kg
    • Shipping Dimensions: 17.5 x 9 x 7.75”
    • Shipping Weight: 5 lbs
    • Shipping Weight (Metric): 2.2 kg
    • Temperature Range: -40°C / +80°C
    • Tilt Drag Settings: Variable Friction Tilt
    • Tilt Lock: Thumb Lock
    • Tilt Range: -60° - +90°

  • Item Includes:

    • GB1 Pan Handle
    • GH03F Head
    • GP1 Base Plate

  • GTIN:

    0847983012091
