Litepanels 936-0301 Astra IP Half Bi-Color LED Panel w/ Standard Yoke - 2700K to 6500K-Integrated Bluetooth App Control

ITEM #: LPAN-936-0301 MFG #: 936-0301

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$825.00

Our Price:

$783.75

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


936-0301 - Overview

Water-resistant, weatherproof, and intended to perform in any environment!

Weighing in at just 6.2lb/2.8kg, the lightweight Litepanels Astra IP 936-0301 Half Bi-Color LED Panel is perfect for small spaces and low ceilings. The most compact in the range, it boasts a powerful 1,500 lux output at 10ft/3m, delivering weatherproof reliable performance and exceptional brightness, rain, or shine.

All-Weather Performance
The industry's best-selling Bi-Color LED panel has evolved. The Litepanels Astra IP 936-0101 is tough and water-resistant, delivering intense output in a lightweight half-size fixture with fast set up for high-performance broadcast lighting in demanding environments.

Power and Punch
Lighting for even the brightest location. With ultra-efficient LEDs and a tight beam angle, Astra IP produces output with impact. Command powerful, flattering, and accurate white light at any intensity, with or without diffusion. Adjust from 2,700K to 6,500K with instant confirmation on the clear LCD screen to match multiple fixtures with confidence.

Ready for Action
From the studio to the street, Astra IP always performs. Rated IP65, Astra IP defies rain, dust, or snow, for seamless operation, whatever the weather. Built tough with an integrated power supply, and optional Gold Mount, V-Mount and BP-U battery plates, Astra IP is the fast fixture that never backs down in any conditions.

  • Features:

    • Built tough: IP65-rated Bi-Color panel with 3-year warranty.
    • Powerful performance: High-output, intense beam.
    • True to life: Accurate color, with no shift at any intensity.
    • Control with confidence: Dual-dial system with LCD screen information.
    • Quick setup: Lightweight, designed for mounted or handheld operation.
    • Off-grid ready: Optional weatherproof battery brackets.
    • Control options: Integrated Bluetooth for app control. Optional Astra IP DMX module.
    • Customizable: Diffusion panel included with optional accessories.

  • Specifications:

    • Optical
    • LED Panel: Bi-Color
    • Beam Angle: 30°
    • Color Temperature Range: 2700°-6500°K
    • Daylight (5600°K) lux @10ft/3m: 1500 (No diff)
    • Tungsten (3200°K) lux @10ft/3m: 1400 (No diff)
    • CRI Average: 95
    • TCLI Average: 95
    • Interchangable Diffusers: Domed (not included), Medium (included)
    • Optics: 30° custom TIR lens

      Operational
    • Lighting Control Modes: CCT/FX with LCD menu control
    • Dimming Control: Constant Current 0-100% Continuous (flicker free)
    • Remote Control Options: Bluetooth [integrated], DMX, RDM [requires separate module]
    • Fan Control: N/A
    • USB Updates: Yes
    • Ambient Temp Operation: -4° to 113° F / - 20° to + 45° C
    • Estimated LED lifetime: 50,000+ hrs
    • Preset Options:
    • -Preset CCT modes with quick select
    • -Customizable user presets with quick select

      Mechanical
    • Versions: Manual
    • Weight: 6.2 lbs / 2.8kg (including yoke and power supply)
    • Mounting Method: TVMP

      Dimensions (without yoke)
    • Height: 7.4" / 18.9cm
    • Width: 14.8" / 37.6cm
    • Depth: 4.2" / 10.6cm

      Dimensions (with yoke)
    • Height: 12.1" / 30.8cm
    • Width: 17" / 43.2cm
    • Depth: 4.2" / 10.6cm

      Electrical
    • Nominal Power Draw: 63W
    • Power Supply: Internal
    • Mains Input: PowerCON True 1, 100-240 VAC / 50-60Hz
    • DC Input: 12-30V
    • IP Rating: IP65

  • Item Includes:

    • 1x Astra IP Half Bi-Color LED Panel
    • 1x Astra IP Half Medium Diffuser (937-0023)
    • 1x PowerCON True 1 Cable

  • Warranty:

    • 3-Year Warranty
