TechLogix TL-MC-1S2R 10/100/1000M Ethernet SFP Media Converter with 1 GE SFP Slot & 2 RJ45 Ports

ITEM #: TGX-TL-MC-1S2R MFG #: 1002-0209

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$136.11

Our Price:

$129.30

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


1002-0209 - Overview

TechLogix media converters adapt fiber signals to a variety of different formats and/or cable types. The TL-MC-1S2R features one SFP port (SFP module sold separately) and two RJ45 twisted pair ports, effectively adapting twisted pair-based devices to fiber for longer transmission distances. The MC-1S2R supports multimode fiber when paired with a multimode SFP module and single mode fiber when paired with a single mode SFP module. Two TL-MC-1S2R media converters are required for most applications - one for each end of the cable run.

  • Features:

    • Convert signals from twisted pair to fiber and vice versa
    • One SFP (fiber) port and two RJ45 (twisted pair) ports
    • 10/100/1000M data rate
    • 850nm/1310nm/1550nm supported wavelengths
    • Single mode and multimode fiber compatible (SFP module dependent)
    • SFP module sold separately
    • Multimode max distance: 550m (1,805 ft.)
    • Single mode max distance: 20km (12.4 miles)
    • 0 degree to 60 degree C operating temperature
    • 1.0" x 2.75" x 3.6" (26mm x 70mm x 93mm)
    • 5V power supply (included)
    • IEEE 802.3z & 802.3ab compliant
    • MDI/MDIX auto-crossover
    • Jumbo frame (64-9216 byte)
    • Voltage monitor support
    • Diagnostic LEDs
    • Plug-and-play compliant
