Triplett LT80-NIST LED Light Meter - White LED Light Sources up to 40000 Fc with Traceability to N.I.S.T.

ITEM #: TRIPL-LT80-NIST MFG #: LT80-NIST

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$329.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


LT80-NIST - Overview

The Triplett Model LT80-NIST LED Light Meter measures light intensity and verify OSHA safety requirements from white LED light sources up to 40k Foot candles (400k Lux. ) now being incorporated in factories, parking lots, schools, offices, transportation lines, warehouses, hospitals, schools, and many other environments. It will also measure light from fluorescent, metal halide, high-pressure sodium, and incandescent sources. It features a 9,999 count LCD display, silicon photodiode sensor with spectral response filter, Min/Max/Avg function that recalls the highest, lowest and average reading, Data Hold to freeze the reading on the display for easy viewing, and auto power off (with disable) to conserve battery life. Includes Certificate of Traceability to N.I.S.T, 2 AAA batteries and pouch case.

  • Features:

    • Measures light intensity from white LED light sources up to 40,000 Fc (400,000 Lux)
    • Measures light from fluorescent, metal halide, high-pressure sodium, and incandescent sources
    • 9999 count LCD display
    • Silicon photodiode sensor and filter
    • Min/Max/Avg function recalls highest, lowest, and average readings
    • Data Hold freezes readings on the display
    • Includes 2 AAA batteries and pouch case

  • Specifications:

    • Display: 4 Digit LCD Display
    • Foot Candle Range: 0 to 40,000 Fc
    • Lux Range: 0 to 400,000 Lux
    • Resolution: 0.01 Fc/0.1 Lux
    • Accuracy: White LEDs: ±3% reading ±30d (0 to 50Fc/0 to 500 Lux)±3% reading(>50FC/500 Lux) Other Light Sources: For reference only
    • Sensor: Silicon light diode and spectral response filter
    • Power: (2) AAA batteries
    • Dimensions/Weight: 5.3 x 1.9 x 0.2" (133 x 48 x 23mm) 8.8oz (250g)

  • Item Includes:

    • 1x Triplett LT80-NIST LED Light Meter
    • 1x Certificate of Traceability to N.I.S.T
    • 2x AAA batteries
    • 1x Pouch case

  • Warranty:

    • 1-year warranty.

  • GTIN:

    0614395003142
