Tripp Lite SRCOOL33K Rack Cooling / In Row Air Conditioner 208V/240V 50/60Hz 33k BTU

ITEM #: TRL-SRCOOL33K MFG #: SRCOOL33K

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$15,522.00

Our Price:

$10,469.69

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Shipped truck freight.


SRCOOL33K - Overview

The harder your data center, network closet or server room works, the more it heats up, leading to inefficient operation, weakened performance and raised cooling costs. In fact, cooling can consume more than half of the power used by a high-density installation—start saving power and money with Tripp Lite’s SRCOOL33K today! The SRCOOL33K provides 33,000 BTU of efficient, reliable cooling in a 42U rack form factor. It features cutting-edge components that limit inrush current and enable precision cooling adjustments to minimize power consumption, maximize cooling and improve your application efficiency. By delivering cold air high in the cold aisle, the SRCOOL33K promotes temperature uniformity from 1U to 42U, allowing your equipment to perform at its peak. Controlling the unit is simple with the intuitive LCD display, or control it from anywhere in the world with the included Modbus card or an optional network interface (Tripp Lite SNMPWEBCARD, sold separately). With the heavy-duty L6-30P plug and exhaust connection directly into the drop ceiling, the unit can be user-installed with no electrician or contractor, saving on up-front costs. Maintenance is no-hassle due to the self-contained design, which requires no water collection tank or extra plumbing, while RoHS compliance and eco-friendly R410a refrigerant means you’ll never have to worry about meeting environmental standards.

  • Features:

    • 33,000 BTU (9.7kW) of cooling power with 1/3 less power consumption
    • Variable-speed, DC-inverter-driven compressor and microprocessor-controlled electronic expansion valve (EEV) enable precision cooling adjustments--no more wasteful, noisy cycling between off and full blast
    • Soft-start feature limits inrush current to prevent introduction of line noise, voltage disruptions and potential circuit overloads
    • Self-contained, zero-maintenance unit re-humidifies condensate and expels it through the exhaust air stream--no floor drain, water collection tank, external condenser, refrigerant piping, duct work or plumbing required

  • Specifications:

    • Model Type Active Cooling
    • Nominal Input Voltage(s) Supported 200V AC; 208V AC; 220V AC; 240V AC
    • Input Connection Type L6-30P Input Cordset
    • Input Cord Length (ft.) 10
    • Input Cord Length (m) 3
    • Input Frequency 50/60 Hz
    • Front Panel LEDs Multi-line LCD control panel
    • Shipping Dimensions (hwd / in.) 85.5 x 26.5 x 46.85
    • Shipping Dimensions (hwd / cm) 217.17 x 67.31 x 119
    • Unit Dimensions (hwd / in.) 78.5 x 23.63 x 43
    • Unit Dimensions (hwd / cm) 199.39 x 60.02 x 109.22
    • Unit Weight (lbs.) 700
    • Unit Weight (kg) 317.51
    • Material of Construction Steel/Aluminum
    • Color Black
    • Cooling Capacity 33,000 BTU / 9.7 kW
    • Dehumidifier 2.5 gal/hour
    • Compressor Type DC inverter driven variable speed
    • Refrigerant R410a (Environmentally friendly, Non ozone depleting)
    • Refrigerant Amount 8.4lbs
    • Air Flow 1200 CFM
    • Amp Draw Nominal Variable
    • Sound Level (Noise) <= 75dB
    • Air Exhaust Tube Length 98 inches
    • Air Exhaust Tube Diameter 9.84 inches
    • Certifications Tested to UL484; CSA, RoHS
    • Product Warranty Period (Worldwide) 1-year limited warranty

  • GTIN:

    0037332172280
