ViewZ VZ-22CMP 22 Inch FHD 1920x1080 CCTV LED Monitor - BNC (1in/1out) / VGA/HDMI - Black Plastic Frame

VZ-22CMP - Overview

• Features:

  • Full HD 1080p Resolution
  • 1 CVBS(BNC) Input / Output (Loop-through)
  • 16:9 / 4:3 Ratio Available
  • Auto Source & Power Recovery
  • HDMI, VGA, Audio
  • 3D Comb-Filter, De-Interlace, Built-in Speakers
  • Built to run 24/7/365


• Specifications:

  • Display
  • Screen Size: 21.5"
  • Max Resolution: 1920 x 1080 @ 60Hz
  • Pixel Pitch: 0.24795mm x 0.24795mm
  • Brightness: 250 cd/m²(Typical)
  • Contrast Ratio: 1000:1
  • Aspect Ratio: 16:9
  • Viewing Angle (H/V): 178°/178°
  • Display Color: 16.7 Million
  • Response Time: < 8ms

    Interface
  • CVBS (BNC) In/Out: 1/1
  • HDMI In: 1
  • VGA In (15Pin D-Sub): 1
  • Audio In: 1

    Audio
  • Built-In Speaker: 2W x 2

    Special Features
  • Filter Type: 3D Comb-filter / De-Interlace
  • Multi-Lingual Language: English, Deutsch, French, Spanish, Italian

    Dimensions & Weight
  • Outline Dimension (WxHxD): 19.32" x 15.08" x 1.52" (490.9mm x 383.1mm x 38.8mm)
  • Net Weight: 4.62lbs (2.1kg)
  • Gross Weight: 6.61lbs (3kg)

    Mount
  • VESA: 75mm x 75mm/M4 x L8mm

    General Summary
  • Transmitter - IR Remote Control: Yes
  • Power - Electrical Ratings: DC 12V, 3A (AC 100V - 240V, 50/60Hz)
  • Power - Consumption: = 22W
  • Regulations: FCC(A), CE, RoHs
  • Operating Temperature/Humidity: 14°F - 122°F (-10°C - 50°C)/5% - 90% RH
  • Compatible Mounts - Wall: VZ-WM05, VZ-WM11, VZ-AM01, VZ-AM02-A
  • Compatible Mounts - Ceiling: VZ-CMKiT-01
  • Compatible Mounts - Rack: VZ-RMK08


• Item Includes:

  • 1x ViewZ VZ-22CMP 22 Inch FHD 1920x1080 CCTV LED Monitor - BNC (1in/1out) / VGA/HDMI - Black Plastic Frame


• Warranty:

  • 3 Year
