ADDER PSU-REDPRO2-16-US PSU Dual Redundant Power Supply - 16 Port

ITEM #: ADR-PSU-RED2-16 MFG #: PSU-RED2-16

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Adder Corporation
Free Shipping with $49 Minimum Order

List Price:

$2,420.00

Our Price:

$2,178.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

PSU-RED2-16 - Overview

The ADDER RED2-16 Dual Redundant 16 Port Power Supply that provides your installation with the power to grow on demand. Housed within a 1U 19-inch rack mount module, the RED2 PSU delivers up to sixteen lockable power 12VDC outputs and is pre-fited with one removable power supply and has remote management.

Resilient: equipped with lockable power units which guard against accidental disconnection
Robust yet lightweight: small form factor, rack mountable device 1U
Ergonomically optimized: all cables and connections can be individually controlled remotely, removing potential points of failure and facilitating the maintenance of your equipment
Easy installation: dispense with the need for mains sockets and power distribution units (PDUs), reducing installation time

  • Features:

    • 16 port independently controllable 12V outputs,
    • 2 hot swappable power modules,
    • Controllable via secure HTTP interface,
    • REST API for 3rd party control integration,
    • 500,000hrs MTBF ratings on power modules,
    • 12V to 5V cable converters available for units with 5V power feeds.


  • Specifications:

    • Mains Inputs:
    • 2 x IEC 90-264VAC 47/63Hz input
    • Efficiency: 92%
    • Power Factor: 0.99 typical
    • Peripheral connections: 1x 8p8c for 10/100 Ethernet connection.

    • Power Outputs: 8 or 16 x locking 3-pin DC connector, 12VDC 20W output. Each output is a Limited Power Service (LPS) to IEC 60950-1.

    • Physical Design: Compact case, robust metal construction. Designed for 19 inch rack mounting: 435mm/17.13" (w), 44mm/1.73" (h), 275mm/10.8" (d), 4.5kg/9.9lbs.

    • Operating Conditions:
    • Temperature 0 to 50C / 32 to 122F
    • Humidity 5 - 90% Non condensing
    • Altitude <2000Meters / 6500ft
    • MTBF 500,000hrs at full load @50C

    • Local Client Requirements:
    • Browser versions
    • Internet Explorer 10,11
    • Firefox 24 ESR and above
    • Chrome 43
    • Standard rack mount ears included


  • Warranty:

    • 2 Year Limited


  • GTIN:

    0657248835293
