L0.0007063 - Overview

The ARRI L0.0007063 SkyPanel S60 is the mid-range model of the SkyPanel, one of the most versatile and brightest soft lights on the market! Featuring a light aperture of 645 x 300 mm and accommodating the vast majority of applications, the S60 is available in fully color tuneable and remote phosphor versions. Unlike other tuneable fixtures, SkyPanel makes no sacrifice when it comes to light output. SkyPanel puts out a tremendous amount of light, in a soft and uniform beam field. Brighter than a 2 kW tungsten soft light or a 6 kW tungsten space light, the SkyPanel S60 has more than enough light for most applications. In some cases the fixture can even compete with natural sunlight; at the same time, it is able to perform beautifully at lower light levels.

SkyPanel is available in three sizes: the S120, S60 and S30. The S60 is a mid-range model, featuring a light aperture of 645 x 300 mm and accommodating the vast majority of applications. The S30 is a smaller, more portable version; half the length of the S60, it is perfect for on-the-go mobile applications. The S120 is twice as long as the S60, but weighs nearly the same.

Incorporating features of ARRI's successful L-Series LED Fresnels, SkyPanel is one of the most versatile soft lights on the market, as well as one of the brightest. Like the L-Series, SkyPanel `C' (Color) versions are fully tuneable; correlated color temperature is adjustable between 2,800 K and 10,000 K, with excellent color rendition over the entire range. Full plus and minus green correction can be achieved with the simple turn of a knob, and in addition to CCT control, vivid color selection and saturation adjustment is also possible.

Unlike other tuneable fixtures, SkyPanel makes no sacrifice when it comes to light output. SkyPanel puts out a tremendous amount o light, in a soft and uniform beam field. Brighter than a 2 kW tungsten soft light or a 6 kW tungsten space light, the SkyPanel S60 has more than enough light for most applications. At the same time, the lamphead is able to perform beautifully at lower light levels. This range of illumination and color gives users an unprecedented amount of control.

Made in Germany to the high standards for which all ARRI products are known, SkyPanel is built to last - constructed from resilient materials and assembled by hand with great care. Other features include an on-board battery input for mobile applications, LAN port for network connectivity, USB-A port for firmware updates via thumb drive, and many more.

The state-of-the-art light engines and electronics built into every SkyPanel have paved the way for a powerful new feature in SkyPanel Firmware 3.0: lighting effects. With SkyPanel Lighting Effects users can now choose and manipulate 12 effects without the need for a lighting console or hours of programming. Each effect has several parameters that allow for customization of the effect to fit your needs. The lighting effects include: candle, clouds passing, club lights, color chase, cop car, fire, fireworks, light strobe, lightning, paparazzi, pulsing, and television. SkyPanel Lighting Effects changes the game for on-set lighting effect generation.

  • Features:

    • The mid-range model SkyPanel
    • Fully Tuneable - between 2,800 K and 10,000 K - Get the color you want in seconds.
    • Tremendous Output. One of the brightest soft lights on the market.
    • True Soft Light Beam Quality. Soft and uniform is the name of the game.
    • Outstanding Color Rendition.
    • LED white light without sacrifices.
    • A Single Soft, Clean Shadow. The proof is in the shadows.
    • Interchangeable Front Diffusor Panels
    • Operate on Location with On-Board Battery Input
    • Largest Light Aperture in its Power Class
    • Thin 5.1" Profile fits into Tight Locations

  • Specifications:

    • Lamphead: S60-C
    • Optical System: Soft Diffusion Panel
    • Light Aperture: 645 x 300 mm / (25.4 x 11.8 inches)
    • Beam Angle: 115° (Half Peak Angle)
    • Weight: Manual Version: 11.7 kg (25.8 lbs)
    • Pole Op Version: 12.8 kg (28.1 lbs)
    • Handling: Steel Yoke, High Strength Tilt Lock
    • Pole Operation Option (Pan & Tilt)
    • Mounting: 28 mm Spigot (Junior Pin)
    • Tilt Angle: +/- 90°
    • Lamphead Voltage Input: 48 V DC
    • Power Consumption: 420 W Nominal, 450 W Maximum
    • Lamphead Power Connection: Male 3-Pin XLR - 15 amp (Pin 1: Negative / Pin 2: Positive)
    • Battery Connector: Male 4-Pin XLR - 10 Amp (Pin 1: Negative / Pin 4: Positive)
    • Battery DC Voltage Range: 23 - 36 V DC
    • Battery Mode Light Output: 50% of Total Output
    • White Light: 2800K - 10000K Continuously Variable Correlated Color Temperature
    • Colored Light: Full RBG+W Color Gamut with Hue and Saturation Control
    • Color Temperature Tolerance: +/-100K (nominal), +/-1/8 Green-Magenta (nominal)
    • Color Rendition: CRI Average > 95
    • TLCI Average > 90
    • Green-Magenta Adjustment: Continuously Adjustable (Full Minusgreen to Full Plusgreen)
    • Dimming: 0 - 100% Continuous
    • Control: On-Board Controller, 5-Pin DMX In and Through, EtherCon LAN Network Connectivity, USB-A
    • Remote Device Management (RDM*): DMX Setup, Hour Counter and Standard RDM Commands
    • Software Interface: Ethernet: DMX Setup, Fixture Status and Firmware Upgrade Through PC, Mac USB-A: Software upgrade via flash drive
    • Housing Color: Blue/Silver, Black
    • Ambient Temperature Operation: -20 - 45°C (-4 - 113°F)
    • Protection Class: IP 20
    • Estimated LED Lifetime (L70): 50,000 hours
    • Estimated Color Shift Over Lifetime: +/- 5% K
    • Certifications: CE, CB, ENEC, cNRTLus, FCC, PSE
    • Power Supply Unit: S60 PSU
    • Power Supply Input Range: 110 - 240 V AC, 50/60 Hz
    • Power Supply Output Range: 48 V DC
    • Power Input Connection: powerCON TRUE1 (Bare Ends / Schuko / Edison Cables Available)
    • Power Output Connection: Female 3-Pin XLR - 10 Amp (Pin 1: Negative / Pin 2: Positive) powerCON TRUE1 (mains power through)
    • Weight: 3.5 kg (7.7 lbs.)
    • Dimension: 383 x 192 x 90 mm (15 x 7.6 x 3.5 inch)
    • Control: On-Board On/Off Switch
    • Mounting: Super Clamp Attachment / SkyPanel PSU Rail Mount

  • GTIN:

    0192223012585
