Ashly Audio NE4250PE 4-Channel Network Enabled Amplifier w/ DSP (4 x 250W at 4 Ohms)

ITEM #: ASH-NE4250PE MFG #: NE4250PE

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$3,099.00

Our Price:

$2,479.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


NE4250PE - Overview

Our multi-channel ne (Networked-Enabled) Series Amplifiers are uniquely designed around an energy efficient Class-D platform with a switching power supply.

Connecting and controlling an amplifier for networked systems has now been simplified with ne Amplifiers. This line offers ease of use, setup and control using standard 10/100 Ethernet protocol and Protea ne Software. No special outboard control units are needed.

Choose either the ne4250 (4-channel) or ne8250 (8-channel) packages rated at 250W per channel, with separate Hi-Z and Low-Z models. ne Series Amplifiers are offered in two separate platforms-the standard network amplifier or a network amplifier with an on-board Protea DSP Processor. Each can be customized for any installation by adding your choice of AES3 inputs, mic pre inputs*, CobraNet or Dante modules.

  • Features:

    • 10/100 Ethernet comes standard for remote control and monitoring
    • FIR Filter capable (with DSP)
    • Low-Z, 25V, 70V, 100V models
    • Protea DSP, AES3, CobraNetr and Danter input options
    • DC voltage remote gain control
    • Switched-mode power supply, Class-D output
    • Stepped, calibrated input attenuators
    • Remote power standby
    • Disable all front panel controls via software
    • Temperature sensitive variable speed fan with side-to-front airflow
    • Selectable HPF frequencies (80Hz, 400Hz, off) on 25V, 70V, and 100V models
    • 4-stage level meters
    • Output current and temp indicators
    • Safety/Compliance: cTUVus, CE, FCC, RoHS

  • Specifications:

    • Controls: Individual input attenuators, AC Power Switch
    • Cooling: Temp dependent speed-controlled fan (Side-in, Front-out)
    • LED Indicators: Unit Status
    • POWER Blue Switch: On, Off
    • STANDBY Yellow Standby, flashing
    • PROTECT Red On, Off
    • DISABLE Yellow On, Off
    • COM Green On, for Ethernet data or Device ID
    • LED Indicators: Each Channel
    • SIGNAL LEVEL
    • Red Clip
    • Yellow -6dB
    • Green -18dB, -12dB
    • BRIDGE Green Per Channel Pair
    • TEMP Yellow Per Channel
    • CURRENT Green Per Channel: Proportional to output

  • GTIN:

    0694970527331
