Atlona AT-PA100-G2 Stereo/Mono Audio Amplifier

ITEM #: ATNO-PA100-G2 MFG #: AT-PA100-G2

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the ATNO-PA100-G2

AT-PA100-G2 - Overview

Small, energy efficient, and affordable, the Atlona Stereo/Mono Audio Amplifier fits the needs of most offices, classrooms, and more. unlike traditional A/B amplifiers the Class D audio amplifier is energy efficient and easily integrated behind a TV where space is limited. Compatible with AT-PA1-IR.

Sometimes a "D" is better than an "A"
Requiring less power, class D amplifiers use an efficient design that reduces size and cost. By removing the need for large space consuming heat syncs and power regulators, the PA100-G2 becomes easy to integrate with a small size that can fit into most spaces.

Use ALL the MICs
Using a captive screw connector and a 3 mode switch, the AT-PA100-G2 changes to meet your needs. Whether its a condenser, dynamic, or wireless MIC the PA100-G2 adapts to you.

Your control needs
Fully adjustable, the AT-PA100-G2 has three control options: RS-232, IR, and Panel Buttons. Built to suit your control needs, adjust the MIC and Line volume or the Bass and Treble levels using the control system you want.

You are the experience
Become part of the audio with a built in MIC mixing feature. Simply speak into your MIC and hear your voice along with the line audio. With only 1ms delay in MIC detection, have no noticeable lag between your words and the audio coming from the speakers

  • Specifications:

    • Input Ports: 2 x RCA connectors, 1 x 3.5mm Audio, 1 x 3.5mm IR, 1 x Captive Screw MIC, 1 x Captive Screw RS-232
    • Output Ports: 1 x Captive Screw Audio, 1 x 3.5mm Loop Out
    • Dimensions (HxWxD): 1.5 x 3.78 x 3.43 (inch) or 38 x 96 x 87 (mm)
    • Weight: 0.66lbs or 0.3kg
    • Power consumption: 3.6W

    • Audio Specifications
    • Gain: 32dB
    • Frequency Range: 20Hz to 20KHz
    • Signal/Noise Ratio: 80dB (at max output)
    • Total Harmonic Distortion: 1% (1KHz), 0.3% (20KHz) -- at nominal levels
    • Input Impedance: Input 1&2: >10K Ohm
    • MIC Input Impedance: 48V: 35K Ohm, MIC: 10K Ohm, LINE: 75K Ohm
    • Output Impedance: 3.5mm Loop Out: 50O stereo, Speaker out: 4 ~ 8 Ohm Amplifier
    • Stereo Channel Separation: >75dB from 20Hz to 20KHz
    • Common Mode Rejection Ratio: >70dB from 20Hz to 20KHz
    • MIC Audio Detection Delay: 1ms

  • Item Includes:

    • 1 x AT-PA100-G2
    • 1 x AC Adapter
    • 1 x User Manual

  • Warranty:

    • 10 Years

  • GTIN:

    0846352003913
