Audix F9 Condenser Microphone - 12-52 V Phantom Power Required

ITEM #: AUD-F9 MFG #: F9

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$169.00

Our Price:

$139.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


F9 - Overview

The f9 is a professional pre-polarized condenser microphone used for stage and studio applications. The f9 is known for its clear, accurate response particularly in the upper frequency range. Ideally suited for a wide variety of acoustic instruments, the f9 is excellent for cymbals, drum overheads, misc. percussion and ambient room miking.

Characterized with a uniformly controlled cardioid polar pattern, the f9 is designed to capture the acoustics of the instrument being miked while at the same time isolating it from the rest of the instruments on stage. The f9 features a 16 mm pre-polarized capsule with gold vapor diaphragm and a frequency response of 40 Hz - 20 kHz.

The f9 is easy to position, durable and manufactured with high standards and tight tolerances. The f9 is manufactured with a precision cast zinc alloy body, durable black E-coat finish and gold plated XLR connector.

  • Features:

    • All-purpose pencil condenser microphone for live
    • sound or home studio
    • Excellent transient response
    • Modular capsule design
    • 3 year warranty

  • Specifications:

    • Transducer Type: Pre-Polarized Condenser
    • Frequency Response: 40 Hz - 20 kHz
    • Polar Pattern: Cardioid
    • Output Impedance: 200 ohms
    • Sensitivity: 8 mV / Pa @ 1k
    • Capsule Technology: Gold Vapor Deposition
    • Equivalent Noise Level: 25 dB (A-weighted)
    • Signal to Noise Ratio: 69 dB
    • Off-Axis Rejection: >24 dB
    • Maximum SPL: ≥137 dB
    • Power Requirements: 12-48 V Phantom
    • Dynamic Range: 112 dB
    • Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
    • Materials/Finish: Zinc Alloy/Black Finish
    • Weight: 3.3 oz
    • Length: 4.37 Inch

  • Warranty:

    • 3 Year

  • GTIN:

    0687471141120
