Belden C6F1106001 CMR 4 Pair Cat6+ F/UTP Patchcord - 24 AWG - Blue - 1 Foot

Name: Belden C6F1106001 CMR 4 Pair Cat6+ F/UTP Patchcord - 24 AWG - Blue - 1 Foot
Brand: Belden
SKU: BL-C6F1106001
Price: 13.46 USD
Availability: PreSale

ITEM #: BL-C6F1106001 MFG #: C6F1106001

Belden

Length:

Length

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$13.46

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

C6F1106001 - Overview

The Belden C6F1106001 is a 1 Foot, CMR/Riser rated, 4 Pair, Shielded Cat6+ F/UTP 24AWG T568A/B-T568A/B Patchcord in Blue. It's recommended for IBDN Shielded System 2400, TIA Category 6, ISO Class E and 1000BASE-T.

Specifications:
- Environmental Space: Riser
- Boot: Elastomer
- Conductor: BC - Bare Copper
- Total Number of Pairs: 4
- Conductor Size: 24 AWG
- Overall Nominal Diameter: 0.26 in
- Wiring Scheme: T568A/B-T568A/B
- Packaging: Individually packaged in a clear plastic bag.
- Front Connection: Blades Phosphor Bronze with 50u inch Gold over Nickel Plating
- Inner Jacket: PVC - Polyvinyl Chloride
- Dielectric Strength: 1,000 V RMS @ 60 Hz for 1 minute
- Current Rating: 1.500 A
- Insulation Resistance: 500 M-Ohm Minimum
- Max Contact Resistance: 20 mOhm
- Installation Temp Range: -10°C To +60°C
- Storage Temp Range: -40°C To +70°C
- Operating Temp Range: -10°C To +60°C
- Min Bend Radius (Overall Cable): 2.080 in
- Plug /Jack Compatibility: RJ45
- UL Rating: Riser
- Data Category: Category 6
- TIA/EIA Compliance: Category 6 - TIA 568-C.2, Class E - ISO/IEC 11801:2002 Ed.2 Amendment 2
- Other Standards: FCC Part 68, Subpart F, IEC 60603-7
- Connection Durabilities: Mated Connection 750 Cycles
- Safety Listing: c(UL)us Listed
