HYPERD/VDUP25/12G - Overview

Sell video at live events the moment they finish!

Concerts, Theatrical Performances, Weddings, Sporting Events, you know the best time to sell content is right after an event when people are still excited about it! Imagine selling a video to fans where they can see themselves in the audience! Now with the Blackmagic Duplicator 4K you can record a concert and make it instantly available while they're buying t-shirts and other memorabilia the moment they leave! Capture a sales conference or technical seminar and provide the attendees a copy of the day's presentation on the spot! When the company's travelling staff get back to the office, they can share it with the team!

The Blackmagic Duplicator 4K is like two recorders in one! Featuring 25 built in SD card recorders, the Blackmagic Duplicator 4K can record to all 25 cards at a time, or be changed to record to a single card at a time for long form recording. When recording to all 25 SD cards, you get a duplicator that gives you 25 x H.264 or H.265 copies that you can sell to customers the moment a live event finishes. Plus when changed to record a single SD card at a time, the Blackmagic Duplicator 4K becomes a powerful long form recorder! With 25 SD cards, you can record for weeks at a time without needing to change the cards out. You can even set Blackmagic Duplicator to automatically clear the oldest card for infinite recording, making it perfect for security and broadcast program logging.

  • Features:

    • Now you can sell video at live events the moment they finish!
    • The new standard for Ultra HD delivery!
    • Content that customers can view on their 4K TVs today!
    • Everything you need to encode, duplicate and sell content at live events!
    • Automatically trigger recording from your camera!
    • Quickly format all cards without using a computer!
    • Record hundreds of copies in real time!
    • Easily merge multiple shots into a single file!
    • Readily available, super thin, inexpensive and high speed
    • No proprietary players needed!
    • Can also be used as a powerful long form recorder!

  • Specifications:

    • SD Card Support Class 10 minimum will support UHS I and UHS II cards.

      Connections
    • SDI Video Inputs: 1
    • SDI Video Outputs: 1 x loop out.
    • SDI Rates: 270Mb, 1.5G, 3G, 6G, 12G.
    • SDI Audio Inputs: 16 channels embedded.
    • SDI Audio Outputs: 16 channels embedded.
    • Optical SDI: Supports optional SMPTE optical module.
    • Optical Outputs: 1 x 10 bit SD/HD/UHD auto switching.
    • SD Card Interface: 25 x SD Card Slots
    • Device Control: l Sony ™ compatible RS422 deck control port. 1 x in plus 1 x out.
    • Ethernet: Ethernet supports 10/100/1000 BaseT.
    • Computer Interface: 1 x USB 2.0 mini port for software updates and Blackmagic Duplicator software control.

      Standards
    • SD Video Standards: 525i59.94 NTSC 4:3 or 16:9, 625i50 PAL 4:3 or 16:9
    • HD Video Standards: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
    • Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60.
    • SDI Compliance : SMPTE 259M, 292M, 296M, 425M Level A and B
    • SDI Metadata Support: HD RP188 and closed captioning.
    • Audio Sampling: Television standard sample rate of 48kHz and 24 bit uncompressed.
    • Video Sampling: 4:2:2

      Product Specifics
    • Duplicate Recording Mode: Duplicate recording mode simultaneously records to all media in Blackmagic Duplicator 4K and to additional units connected via RS422.
    • Single Disk Recording Mode: Single Disk recording mode records sequentially to all media in the primary Blackmagic Duplicator 4K, then sequentially to additional units connected in series via RS422. Recording will automatically stop when media in all units is full.
    • Disk Overwrite Recording Mode: Disk Overwrite recording mode records sequentially to a single Blackmagic Duplicator 4K, overwriting media in a continuous loop until the recording is stopped.
    • Record Codec: 8 bit H.264 or 10 bit H.265 at 4:2:0 with ACC audio.
    • Display: 1x built in high res LCD 320 x 240 for menu settings, status, format, audio level and total number of SD cards.
    • Physical Installation: 1 rack unit size. Less than 7 inches deep.

      Media
    • Media: 25 x UHS I for SD, HD and Ultra HD recording.
    • Media Type: Class 10 minimum. SDXC UHS I and SDHC UHS I SD cards. Also supports UHS II SD cards.
    • Media Format: Can format cards to ExFAT file system.

      Control
    • Built in Control Panel: 6 buttons for transport and menu control. Includes record, append record, stop, menu, remote and control panel lock buttons. 2.2 inch color display.
    • External Control: RS 422 deck control, SDI start/stop, timecode run. Includes Blackmagic HyperDeck SDK and Ethernet HyperDeck Control Protocol.

      Software
    • Software Included: Blackmagic Duplicator
    • Internal Software Upgrade: firmware built into software driver. Loaded at system start, or via updater software

      Operating Systems
    • Mac 10.13 High Sierra, Mac 10.14 Mojave or later. Windows 8.1 and 10.

      Power Requirements
    • Power Supply: 1 x Internal 100 240V AC.

  • Item Includes:

    • Blackmagic Duplicator 4K
    • Software SD Card

  • Warranty:

    • 12 Month Limited Manufacturer's Warranty.

  • GTIN:

    9338716003918
