C2G 43175 CMP/Plenum HDBaseT Certified Cat6a Cable w/Discontinuous Shielding - 150 Foot - Blue

ITEM #: C2G-CG43175 MFG #: CG43175

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$511.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    CG43175 - Overview

    This Snagless Discontinuous Shielded Cat6a patch cable is ideal for use with HD A/V applications from HDBaseT extenders and Power over Ethernet (PoE) applications requiring higher levels of current. The HD A/V application is perfect for conference rooms and digital signage where greater distance requirements are needed between a source and a display. Each patch cable is fully tested to meet ANSI/TIA 568 C.2 Cat6a channel requirements.

    HDBaseT Certified
    These cables have been tested and validated to guarantee they consistently meet the highest industry performance and safety standards.

    Design Features
    The uniquely designed Isolation Wrap contains discontinuous sections of metallized material, held in place by a polymeric layer. These cables have a nominal 0.265" diameter that allows for higher cable density and smaller bend radius than other Cat6a cable products. These cables are also designed for Power over Ethernet (PoE) applications type 1-4 according to IEEE 802.3bt draft D1.2.

    Discontinuous Shield
    These cables have discontinuous metallic shielding elements surrounding the inner 4-pair core of the cable. The effect of this approach is to attenuate both electromagnetic signals that emanate from the cable core and the potentially interfering electromagnetic signals that are generated by other sources. The metallic shielding elements are designed to be discontinuous to avoid any need for grounding, which is a requirement for shielded cable designs, and have been shown to provide superior Alien Crosstalk performance in comparison to conventionally designed Category 6A UTP cables.

    • Features:

      • Discontinuous shielding avoids need for grounding
      • HDBaseT Class A and B certified
      • Designed to support up to 10 Gigabit data transmission
      • Snagless design for high density applications

    • Specifications:

      • Cable type: Solid Non-Continuous FTP
      • Wiring scheme: 568B
      • Temperature rating: 75°C
      • Separator Cross-web
      • Isolation Wrap: Proprietary construction
      • Jacket: CMP: FR, low smoke PVC
      • Conductor type: 23AWG (0.57mm) (solid annealed copper)
      • Characteristic Impedance: 100
      • Testing: ANSI/TIA 568 C.2 Cat6a channel tested
      • Sustainability: UL Certified EPD, HPD, Multi-Attribute Certification, USGBCr Member, RoHS-compliant/RoHS 2-compliant, REACH-compliant
      • Performance Compliance: UL 444, CSA C22.2 No. 214-08, UL 1666, NFPA 262, ANSI/TIA-568-C.2, Article 800, NEC (NFPA 70), HDBaseT Class A and B
      • NRTL Programs: UL Verified CAT 6A, UL, c(UL) Listed CMR, UL, c(UL) Listed CMP, HDBaseT Certified
      • Connector Type: RJ-45 Male
      • Housing: Polycarbonate
      • Contacts: 50µm gold plated
      • Hood: Molded Snagless PVC
      • Dimension (L x W x H): 38.2 x 11.6 x 15.1mm


    CG43175 - Required Accessories
