Digital Forecast UHD X MC 12G Cross and Dual Scaler Converter with HDMI 2.0 and 12G-SDI

UHD X MC - Overview

• Features:

  • Standard SDI (HD, 3G, 6G, 12G) format supported
  • Standard HDMI (Max 4096x2160) format supported
  • Analog Audio MUX/DMX supported
  • Convenient setting support through Front OLED Display
  • Dual UHD 4K Scaler (SDI/HDMI Output can be set individually)


• Specifications:

  • Digital Video
  • HD: 720p (60/59.94/50), 1080i (60/59.94/50), 1080p (23.98/24/25/29.98/30)
  • FHD: 1080p (60/59.94/50)
  • 2K/4K: 2160p (23.98/24/25/29.98/30)
  • 4K: 2160p (60/59.94/50)

    General
  • Inputs:
    - 1x HDMI 2.0 Input
    - 1x 12G SDI Input
    - 1x 12G SDI Thru Output
    - 1x 12G Optic Input
  • Outputs:
    - 1x HDMI 2.0 Output
    - 2x 12G SDI Outputs
    - 1x 12G Optic Output
  • Power Level: +12 VDC
  • Power Consumption: 10 Watts
  • Operating Temperature: -4°F - 158°F (-20°C - 70°C)
  • Humidity: 0% to 95% RH, non-condensing
  • Dimensions: 8.27" x 4.14" x 1.5"
  • Weight: 1lb


• Item Includes:

  • 1x DF-UHD-X-MC Dual Scale Converter
  • 1x AC/DC power adapter
  • 1x Phoenix Terminal Block Connector (Audio)
