ALP-DANTE-LE - Overview

The ALP-DANTE-LE concentrates Digigram's expertise into a lighter version of the ALP-DANTE PCIe sound card without sacrificing its most prominent features.

This new audio interface has just the features you need, no more and no less: versatility, reliability, untouched audio quality, plus cost-effectiveness. ALP-DANTE-LE comes with adjusted connectivity, while keeping the same number of channels. This optimized card will power a larger array of 365/24/7 run applications that require recording, playout or real time processing.

ALP-DANTE-LE uses the same sturdy hardware platform as the rest of the ALP-X range, whose proven design is a synonym for legendary reliability. The card also features the famous low-profile form factor, coupled to a fanless design to address audio applications where space and reliability are at stake. ALP-DANTE-LE operates under Windows and Linux drivers and is compatible with AES67 and SMPTE 2110-30 protocols, increased versatility to address countless applications regardless of the environments. Lastly, the card seamlessly integrates Dante networks thanks to the Dante Controller interface, and Digigram's signature reliability and low latency coupled with the audio quality inherent in the Dante protocol.

  • Features:

    • Outstanding audio quality and performance
    • Onboard high quality mic preamps
    • Rock-solid, life-long, hiccup-free reliability
    • Fits in any type of PC / workstation / server with a PCIe slot
    • Made for regular application or custom design with help of Digigram control API

  • Specifications:

    • Network Connectivity: 2x Gbps Eth ports that can be used in redundancy mode (Pri, Sec), or in switching mode
    • Input and Output Channels:
      - 64 x 64 channels at 44.1kHz and 48 kHz
      - 32 x 32 channels at 88.2 kHz and 96 kHz
      - 16 x 16 channels at 176.4 kHz and 192 kHz
    • Audio Flows: Maximum 32 input and 32 output streams
    • Buffering: Up to 2000 samples per channel (41.7ms at 48 kHz)
    • AoIP Compatibility: Support for AES67 and SMPTE ST2110-30
    • Sample Format: PCM 16, 24, 32 bits
    • Management: Audinate Dante Controller and Dante Domain Manager
    • Firmware: Via the application AVS-Monitor (available from the Auvitran WEB site)
    • Supported Operating Systems:
      - Windows (as of Windows 10 and Server 2019)
      - Ubuntu ver 20.04 kernel 5.15
      - Ubuntu ver 22.04 kernel 6.5
      - Debian 11 kernel 5.10
      - Debian 12 kernel 6.1
      - Red Hat Enterprise Linux (RHEL) 9 kernel 5.1
      *Note: Source code available for compiling drivers for other Linux distributions
      *Note: Optional service for generating a driver for other Linux distributions
    • Dimensions (Low Profile): 6.6" x 2.7" x 0.8" (168mm x 69mm x 20mm)
    • Dimensions (Standard Profile): 6.6" x 3.9" x 0.8" (168mm x 99mm x 20mm)
    • Form Factor: Low profile PCIe (Additional full-height bracket provided for installation in standard height slots)
    • Expansion Bus: PCI Express TM (PCIe TM) x1 (x2, x4, x8, x16 compatible)
    • Windows Drivers: Asio, Wasapi/DirectSound
    • Linux Drivers: Alsa
    • One Driver Package: Multi-application and multi-card (API available to access the parameters)

  • GTIN:

    0641094064327
