Ensemble Designs BENXT-910K-SC BrightEye NXT 910-SC Crop and Scale License for the BENXT-910 (download)

BENXT-910K-SC - Overview

• Features:

  • Amazing Features - And Amazingly Compact
  • Web Interface with Video Proxies
  • Automatic Format and Frame Rate Conversion
  • From SD to 3G, and Everything In-between
  • Video Proc Amp and Color Correction
  • Audio Channel Swap and Level Adjust
  • SFP ports for HDMI, Fiber, Composite, or additional SDI I/Os
  • HDMI and HDCP Support
  • Front Panel Live Monitor
  • Monitor Pre- and Post-Processed Signals


• Specifications:

  • Serial Digital Outputs
  • Number: Four
  • SDI Standards Supported - for both Input and Output:
  • 1080i 50, 59.94 or 60 Hz, SMPTE 274M -4,5,6
  • 720p 50, 59.94 or 60 Hz, SMPTE 296M -1,2,3
  • 1080p 23.98, 24 or 25 Hz, SMPTE 274M -9,10,11
  • 1080p 50, 59.94, 60 Hz, SMPTE 424M, 425M, Level A
  • 1080sF 23.98, 24 or 25 Hz, RP211 -14,15,16
  • 625i 50
  • 525i 59.94

    HDMI Inputs
  • Number: Four
  • Type: HDMI 1.3
  • Audio: Up to 8 Channels
  • HDCP: Supported

    Standards:
  • 1080i 50, 59.94 or 60 Hz, SMPTE 274M -4,5,6
  • 720p 50, 59.94 or 60 Hz, SMPTE 296M -1,2,3
  • 1080p 23.98, 24 or 25 Hz, SMPTE 274M -9,10,11
  • 1080p 50, 59.94, 60 Hz, SMPTE 424M, 425M, Level A
  • 1080sF 23.98, 24 or 25 Hz, RP211 -14,15,16
  • 625i 50
  • 525i 59.94

    HDMI Monitor Output
  • Number: One
  • Type: HDMI 1.3
  • Audio: 8 Channels
  • Format: Follows channel configuration

    SFP (Small Format Pluggable) Interfaces
  • Number: One
  • Ports-HDMI: One per SFP
  • SDI, Fiber: Two per SFP
  • IP Encapsulate (SMPTE 2022, and more): One per SFP
  • Usage: Assignable to Channel Input or Output
  • As Input: in place of SDI or HDMI
  • As Output: in addition to SDI

    Frame Synchronizers
  • Number: Four
  • Range: Infinitely adjustable in H and V
  • Format Conversion *Requires License in NXT 910
  • Integrated with Frame Synchronizer
  • Automatic conversion from any input to configured output format
  • Crop and Scale *Requires License in NXT 910
  • Sample Rate Conversion of Embedded PCM Audio


  • SDI Inputs: Supports 16 channels
  • HDMI Inputs: Supports 8 channels
  • Re-Synchronization of encoded Surround Sound Dolby-E, Dolby-D, AC-3 Automatically detected
  • Number: One
  • Type: 1 V P-P Composite Video, PAL or NTSC or Tri-Level Sync
  • Impedance: 75 Ω
  • Return Loss: >40 dB
  • Type: RJ-45
  • Speed: 10/100 Mb/s
  • Protocols: HTTP, TCP/IP
  • Size: 5.63 in x 1.65 in x 6.75 in / 143 mm x 42 mm x 172 mm including connectors and flange
  • Weight: 1 lb 12oz
  • Power: 12 volts, 35 watts (100-230 VAC modular power supply)
  • Temperature Range: 32F to 104F / 0 to 40C ambient (all specs met)
  • Relative Humidity: 0 to 95 %, non-condensing
  • Altitude: 0 to 10,000 ft.
