ETS AV906 Baseband Video/Stereo Audio Balun - 2 RCA Audio & 2 RCA Video Inputs to RJ45

Name: ETS AV906 Baseband Video/Stereo Audio Balun - 2 RCA Audio & 2 RCA Video Inputs to RJ45
Brand: ETS
SKU: ETS-AV906
Price: 94.13 USD
Availability: PreSale

ITEM #: ETS-AV906 MFG #: AV906

ETS

Versions:

Versions

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$117.70

Our Price:

$94.13

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

AV906 - Overview

The ETS AV906 allows you to send two channels each of baseband video and audio in any direction desired. This capability yields, for instance, a bi-directional video and mono audio link, or many other configurations.

The ETS Baseband Video/Stereo Audio Baluns are utilized for point-to-point replacement of coaxial (video) and shielded (high impedance audio) cables with UTP wiring, Category 5 or better.

Features:
- Baseband video and balanced audio channels on one run of UTP
- Use for point to point replacement of coax and shielded cables
- Rugged plastic cases
- 100% tested
- Made in USA
Specifications:
- Bandwidth: Flat to 60MHz (video)/10Hz to 20kHz (audio)
- Connectors: 2x RCA jack (video)/2x RCA jack (audio) to RJ45 jack, Data Pass Through (audio)
- Crosstalk: >50dB (video)
- Impedance: 600:600 (audio)
- Isolation: 500 V (audio, per channel)
- Distance: Audio - 1000ft; Video: Color - 1200ft, B/W - 2500ft
- Dimensions: 2.60" x 2.60" x 1.10" (66mm x 66mm x 28mm)
- Net Weight: 3.17oz (0.09kg)
