Hollyland Pyro 7 2.4GHz/5GHz Dual Band 7 Inch Wireless Transceiving Video Monitor - HDMI 1.4b/3G SDI - 1300ft/400m

Name: Hollyland Pyro 7 2.4GHz/5GHz Dual Band 7 Inch Wireless Transceiving Video Monitor - HDMI 1.4b/3G SDI - 1300ft/400m
Brand: Hollyland
SKU: HL-PYRO-7
Price: 549.00 USD
Availability: PreSale

ITEM #: HL-PYRO-7 MFG #: HL-PYRO 7

Hollyland

Our Price:

$549.00

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

HL-PYRO 7 - Overview

With Auto Dual-Band Hopping (ADH) technology, Hollyland's Pyro 7 is a 7-inch wireless monitor that supports 2.4GHz/5GHz dual-band transmission and automatic frequency hopping. It has a remarkable transmission range of up to 1,300ft (400m) and an incredibly low latency of only 60ms. The cutting-edge hardware design enables Pyro 7 to support one transmitter connecting to four receivers simultaneously, and it also offers the convenience of dual-camera monitoring through customizable shortcut keys. In addition, the upgraded HollyOS system provides enhanced image analysis capabilities and allows for video file export via an external SD card.

Features:
- 1TX & 4RX
- 1300ft (400m) & 60ms Latency
- 2.4GHz & 5GHz Dual Band
- Auto Frequency Hopping
- TX, RX, and Monitor — All in One
- Dual-View Quick Monitoring Switch
- 7 Inch & 1200 nits
- Precise Image Analysis
- SDI & HDMI Loopout
- RTMP Streaming
- NP-F Battery Plate
Specifications:
- Input Port: HDMI 1.4b + 3G SDI
- Output Port: HDMI 1.4b + 3G SDI
- Antenna: RP-SMA Male x2
- Power Input: DC Input (2.0mm core socket)
- Headphone Jack: 3.5mm
- Upgrade Port: USB-C (USB 2.0 OTG); SD Card Slot
- Screen Size: 7" Touchscreen
- Screen Resolution: 1920 x 1200 pixels
- Pixel Density: 323 PPI
- Aspect Ratio: 16:9
- Contrast Ratio: 1000:1
- Power Input Voltage: 10 - 18V/2.5A DC Input (nominal 12V)
- Power Consumption: < 22W
- Net Weight: ≈ 19.2oz (545g) with battery plate included and external antennas excluded
- Dimensions: 7.1" x 5" x 1.25" (180 x 127 x 31.8mm) with battery plate and external antennas excluded
- Operating Frequency: 5.1 - 5.8 GHz; 2.412 - 2.484 GHz
- Transmit Power: ≤ 23 dBm
- Receiver Sensitivity: -80 dBm
- Display Latency: < 50ms
- Transmission Latency: ≈ 60ms (test data when 1080p60 signals are transmitted in a laboratory)
- LOS Range: 1,300ft (400m); 650ft (200m) in Broadcast mode (Connection to the monitoring app may affect the range)
- Bandwidth: 20 MHz; 40 MHz (in Broadcast mode)
- Audio Format: HDMI 1.4b 8-Channel
- Operating Temperature: 14°F - 113°F (-10°C - 45°C)
- Storage Temperature: -40°F - 140°F (-40°C - 60°C)
- HDMI Input:
  - 720p 50/59.94/60
  - 1080i 50/59.94/60
  - 1080p 23.98/24/25/29.97/30
  - 1080p 50/59.94/60
  - 3840*2160 23.98/24/25/29.97/30
- HDMI Loopout:
  - 720p 50/59.94/60
  - 1080i 50/59.94/60
  - 1080p 23.98/24/25/29.97/30
  - 1080p 50/59.94/60
  - 3840*2160 23.98/24/25/29.97/30
- SDI Input:
  - 1080p 50/59.94/60 (Level A)
  - 1080p 50/59.94/60 (Level B)
  - 1080i 50/59.94/60
  - 1080psf 23.98/24
  - 1080p 23.98/24/25/29.97/30
  - 1080psf 25/29.97/30
  - 720p 50/59.94/60
- SDI Loopout:
  - 720p50/60
  - 1080i 50/60
  - 1080p 24/25/30
  - 1080p 50/60
  - 1920*1080 24/25/30
- HDMI/SDI Output:
  - 720p 50/60
  - 1080i 50/60
  - 1080p 24/25/30
  - 1080p 50/60
  1920*1080 24/25/30
- SDI/HDMI Loopout:
  - 1080p 50/59.94/60 (Level A)
  - 1080i 50/59.94/60
  - 1080p 23.98/24/25/29.97/30
  - 1080p 23.98/24
  - 1080i 50/59.94/60
  - 720p 50/59.94/60
- SDI/HDMI Output:
  - 1080p 50/59.94/60 (Level A)
  - 1080i 50/59.94/60
  - 1080p 23.98/24/25/29.97/30
  - 1080p 23.98/24
  - 1080i 50/59.94/60
  - 720p 50/59.94/60
Item Includes:
- 1x Pyro 7 Wireless Transceiving Monitor
- 2x Paddle Antenna (2.4 GHz & 5 GHz)
- 1x User Manual
- 1x Warranty Card
- 1x D-Tap to Locking DC Power Adapter Cable
- 1x Secure Digital Memory Card (32G)
- 1x USB-C OTG Adapter
GTIN:
0191460006098

HL-PYRO 7 - Recommended Accessories

Laird 12G-SDI/4K Mini-RG59 Belden 4855R UHD Single Link BNC Cable - 10 Foot - Black
4855R-B-B-BK-010
Our Price: $34.49
Connectronics ULTRA High Speed 8K HDMI 2.1 AM/AM Cable - 6 Foot
HDMI-21-06FT
Our Price: $7.49
SanDisk SDSDXXY-128G-GN4 Extreme PRO SDHC & SDXC UHS-I Card - 128 GB
SDSDXXY-128G-GN4
Our Price: $52.95
Vidpro Power2000 ACD-6072BC 2x Batteries + Dual Bay LCD Charger Kit for Sony NP-F970
VDP-ACD-6072BC
Our Price: $75.00
ikan DV-DUAL-S750 DV Camera Battery Kit w/ 2 Sony NP-F750 5800mah Replacement Lithium Batteries and Dual Battery Charger
IKAN-DVDUALS750
Our Price: $89.99
Connectronics USB-C to USB-C Male to Male Gen2 10Gbps USB 3.1 Cable - 3 Foot
USB3-CM-CM-003
Our Price: $9.99
Delvcam VGRIP-1 Multi-Arm Super Clamp Mount For Cameras - Lights - Monitors - Mics Fits All 1/4-20 Holes Up To 10 Lbs
VGRIP-1
Our Price: $99.95
Sony Pro MDR-7506 Foldable Large Diaphragm Headphones
MDR-7506
Our Price: $99.99
Delvcam Swivel Mount Adapter
DELV-SM
Our Price: $32.95
