IDX CUE-H90 90 Watt-Hour Li-Ion V-Mount Battery with 1x D-Tap

CUE-H90 - Overview

• Features:

  • Meets passenger aircraft carry-on regulations
  • 80W D-Tap to power accessories
  • 4-LED Power Indicator
  • Updated slim and compact casing
  • 30% smaller than outgoing CUE-D95
  • Greater capacity than CUE-D75 with similar profile


• Specifications:

  • Capacity: 90Wh (14.8V/ 6.02Ah)
  • Max Output Voltage: 16.8V DC
  • Nominal Voltage: 14.8V DC
  • Max Discharge Current: 7A
  • D-Tap: 80W each
  • End Voltage: 11.2V
  • Battery Protection: Over charge, Over discharge, Over current

    Ambient Temperature
  • To charge: 32°F ~ 104°F (50°F ~ 86°F recommended)
  • To discharge: -4°F ~ 113°F (50°F ~ 104°F recommended)
  • To store: -4°F ~ 113°F (less than 1 month)


  • Dimensions: 3.82(W) x 5.75(H) x 1.54(D) inches
  • Weight: 1.34 lbs approx.


• Item Includes:

  • 1x IDX CUE-H90 91 Watt-Hour Li-Ion V-Mount Battery with 1x D-Tap


• GTIN:

  0825781013175
