Kramer 900N Stereo Audio Power Amplifier (10 Watts per Channel)

900N - Overview

High-performance power amplifier

• Features:

  • High Efficiency - Class D operation.
  • S/N Ratio - 55dB.
  • Controls - Volume knob, On LED.
  • Special Note - Before turning on the 900N, make sure the volume is turned down to the minimum.
  • Compact Kramer TOOLS™ - 3 units can be rack mounted side-by-side in a 1U rack space with the recommended rack adapter.


• Specifications:

  • INPUTS
  • 1 unbalanced stereo audio on RCA connectors
  • 1 balanced stereo audio on a 5-pin terminal block connector


  • OUTPUT
  • 1 stereo loudspeaker output on a 4-pin terminal block connector


  • OUTPUT POWER
  • 10W RMS per channel into a 4Ω load


  • OUTPUT MUSIC POWER
  • 35W RMS per channel into a 4Ω load


  • BANDWIDTH (-3DB)
  • 24kHz


  • S/N RATIO
  • 55dB


  • CONTROLS
  • Gain: - 40dB to +19dB until the compression threshold


  • COUPLING
  • Input: AC
  • speakers out: DC


  • AUDIO THD + NOISE
  • 0.5% @1kHz


  • AUDIO 2ND HARMONIC
  • 0.04% @1kHz


  • POWER CONSUMPTION
  • 12V DC, 2.1A


• Item Includes:

  • 900N Amplifier
  • Power Supply
  • Mounting Bracket


• Warranty:

  • Limited 7 Year Warranty


• GTIN:

  7291063028251
