MR-NET+ Self Redundant Streaming IP Multi-Router Kit with Epiphan PEARL NANO All-In-One Video Production System

ITEM #: MTN-MRNETPRL-KIT MFG #: MTN-MRNETPRL-KIT

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$4,499.99

Our Price:

$3,999.00

Availability: In Stock
iAvailability Description Popup


MTN-MRNETPRL-KIT - Overview

Never worry about internet connectivity again when streaming your live productions - MR-NET+ is here to save the day! This next-generation, self-contained system allows you to create your own ISP for video streaming in sports, concerts, live events and education. MR-NET's Network-as-a-Service platform provides you with Internet access in any location within minutes, without long term contracts or hardware expenses. The magic behind the service is that they bond the best available carriers into a self-redundant and high speed connection, sending data securely to its final destination.

The Epiphan Video Pearl Nano™ is the ultimate portable hardware encoder. Pearl Nano offers incredible versatility with a refined yet robust feature set that includes ingestion, encoding, HDMI pass-through, and recording. Streamline your setup with the ability to directly connect HDMI and SDI video sources and XLR, RCA, or USB audio to Nano along with Power over Ethernet Plus (PoE+). For zero-latency display of video sources on in-room monitors, Nano also features a built-in HDMI pass-through.

Please Note:
The included Premium Video Service Package License is for 1 year only and must be renewed anually.

Data package is sold separately and required to operate. Please call for details.

  • Features:

    • MR-NET+
    • 3 LTE Modems Bonded Together to Provide a Redundant Connection up to 100 Mbps
    • Comes with SIMs for all Top Tier Cellular Networks. No throttles, No Caps, Always ON.
    • PoE or AC Adaptor Power Supply
    • WAN port for Existing Broadband which can be set up in Failover or Bonding Modes
    • Shockproof travel case (MRNET+ feature)
    • Customer Suite Provides Universal Transparency
    • 24/7 Oversight Ensures Seamless Connectivity and Avoids Service Interruption
    • AI Based Failure Detection and Resolution
    • Plug-n-Play setup - No Technician Needed
    • 2.4 / 5 GHz Wi-Fi network (optional)

      Pearl Nano
    • Front screen for basic configuration/control and confidence monitoring
    • Video inputs for HDMI and SDI
    • Audio inputs for line-level XLR, RCA, and USB
    • HDMI program out and pass-through for zero-latency content display
    • Custom layout builder for a tailored video program
    • Intuitive browser-based UI and local console
    • Cloud-based configuration and control via Epiphan Cloud
    • SRT, HLS, MPEG-DASH, RTMP, and RTMPS streaming protocol support
    • Secure Sockets Layer (SSL)
    • Comprehensive integration with Kaltura and Panopto
    • Power over Ethernet Plus (PoE+) and DC power
    • Save recordings directly to an SD card (user supplied)
    • Expansion bay for user-supplied M.2 SATA SSD
    • Automatically transfer recordings to a USB drive or networked server
    • 802.1x network access control
    • Lightweight Directory Access Protocol (LDAP)
    • Integration with Crestron Systems

  • Specifications:

    • MR-NET+
    • Routing/Switching Protocols - Pv4/IPv6, Session persistent failover, NAT, GRE, Port Forwarding
    • IP Applications - DDNS, DNS Proxy, DHCP / DHCPv6
    • VLAN & VPN - VLAN, IPSec, VPN Failover
    • Wi-Fi* - Wi-Fi Hotspot, can be used as additional bonding input
    • Security - Firewall, e2e encryption for each individual gateway
    • 3 LTE - Up to three independent LTE connections
    • 1 WAN - External WAN 100BASE-T DSL / Ethernet connections
    • 2.4/5 GHz - Wi-Fi IEEE 802.11.b/g/n/a 2.4GHz / 5GHz bands
    • LTE support: 3 LTE-A cat6 modems (Quectel EP06-A)
    • Supported carriers: Verizon, T-mobile, AT&T
    • Operating bands: LTE-FDD: B2, B4, B5, B7, B12, B13, B25, B26, B29, B30, B66 / WCDMA: B1, B4, B5
    • Ethernet RJ45: 2x 10/100 Ports (1 x LAN 1 x WAN optional)
    • Voltage: 12-18 V
    • Passive PoE Support: Input only
    • Power Consumption: ~18 W
    • Operating Temperatures: 32°F - 95°F
    • Air Humidity: up to 80%
    • Weight: 1.7lbs
    • Dimensions: 8.3" x 1.9" x 5.9" deep (not including antennas)

      Pearl Nano
    • Video Input Connectors: 1x HDMI 2.0, 1x 12G SDI, 1x USB Type A
    • Video Network Inputs: SRT and RTSP
    • Audio Input Connectors: 2x XLR line level (stereo pair or two mono), 1x USB, 1x SDI, 1x HDMI, 1x RCA
    • Audio Gain Control: 0dB - 30dB
    • Video Outputs: 1x HDMI pass-through, 1x HDMI program out
    • Video Encoding Codecs: H.264, H.265 (paid upgrade)
    • Color Resolution: 4:2:0
    • Resolution: User selectable up to 1920 x 1200 (4K coming soon as a paid upgrade)
    • Streaming Protocols: RTMP/RTMPS, SRT, HLS, MPEG-DASH, RTSP, MPEG-TS, UPnP
    • Encoded Programs: 1x 1080p program @ 60 fps (with up to 2 Full HD sources; 4K coming soon as a paid upgrade)
    • Audio Encoding: MP3, PCM, and AAC (sampling 16 to 48 kHz with bitrate up to 320 kbps)
    • Network Connections: 1x 10/100/1000 Ethernet port (RJ45)
    • SD Card Storage: Up to 512 GB EXT4
    • Internal Storage: SATA M.2 2280 SSD (M Key connector)
    • Local USB Storage: Automatic or manual copy via 1 USB 3.0 port
    • Network Storage: FTP, SFTP, SCP, RSYNC, CIFS, AWS, or WebDav servers
    • Recording Formats: AVI, MP4, MOV, or MPEG-TS
    • Dimensions (WxDxH): 8.11" x 5.87" x 1.61" (206mm x 149mm x 41mm)
    • Weight: 2lbs (907g)

  • Item Includes:

    • 1x MR-NET+ Self Redundant Streaming IP Multi-Router
    • 1x Epiphan Pearl Nano All-In-One Video Production System
