Netgear AV Line M4350-36X4V 36x10G/Multi-Gig PoE++ and 4xSFP28 25G Fully Managed Switch

ITEM #: NG-XSM4340CV MFG #: XSM4340CV

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
NetGear AV
Free Shipping with $49 Minimum Order

List Price:

$10,919.52

Our Price:

$6,999.99

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

XSM4340CV - Overview

The Netgear XSM4340CV is a fully managed switch designed for AV over IP out of the box. With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

Fast, Easy Configuration for AV Pros
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 switches.

Power and Throughput
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.

  • Features:

    • 36 10G/Multi-Gig PoE++ ports with 4 25GBASE-X SFP28 uplinks
    • 750W internal power supply providing 280W of PoE budget
    • 1 slot for modular power supply (1+1 redundancy and/or EPS share)
    • Any APS600Wv3, APS1200Wv2, or APS2000Wv2 can be used
    • The PoE budget can reach 1,760W, when the redundant PoE budget remains 280W
    • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
    • Layer 3 feature set includes static, policy-based, and dynamic routing


  • Specifications:

    • Primary Port Speed: 10 Gigabit / Multi-Gig
    • Number of Ports: 40 (36 x 10G/Multi-Gig PoE++, 4 x 25G SFP28)
    • PoE Ports / Budget: 36 PoE++ (90W/port), 280W Base, up to 1,760W Budget
    • IGMP Support: Enhanced (NETGEAR IGMP Plus™)
    • Jumbo Frame Support: Yes, up to 12kb
    • AVB Support: Yes, included
    • Acoustics: Quiet Mode 32.1dB@25°C
    • Power Consumption:
      With PoE: 454W/1548.14Btu/hr
      Without PoE: 148W/464.72Btu/hr
      Standby without any port connection: 59.3W/186.2Btu/hr


  • Item Includes:

    • 1x M4350-36X4V (XSM4340CV)
    • 1x Power cord(s)
    • 1x Console USB Type-C
    • 1x Rack-mounting standard bracket set
    • 1x Set of longer brackets for recessed mounting
    • 4x Rubber footpads for tabletop installation
    • 1x Installation guide


  • Warranty:

    • Lifetime with Registration
