Smart-AVI QKVMDP Ultra-HD Quadruple View KVM Switch with Multiview Preview Screen - 4-Port DisplayPort / USB 2.0

ITEM #: SAVI-QKVM-DP MFG #: QKVMDP

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$2,999.00

Our Price:

$2,599.13

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    QKVMDP - Overview

    The Smart-AVI QKVMDP can be used in many applications that require the real-time monitoring of multiple computers. It is a perfect solution in situations where a user needs to monitor several computers at the same time. In Air Traffic Control environments, several computers need to be monitored for the progress of flights and flight information. The QKVMDP is perfect for multitasking, allowing the user to run tasks on each computer and monitor their progress without having to switch back and forth between them.

    Applications:
    Corporate or Educational Presentations
    Financial (Remote Servers/User Control)
    Call Centers for Technical Support
    Industrial (Long-Range Workstation Isolation)
    Airport Installations (Air Traffic Control/Passenger Information)
    KVM Extension where Exceptional Quality of Signal is Crucial
    Medical (Remote Operation Away from Sensitive/Magnetic Equipment)
    Recording (for Large Studios where Editing/Mixing Stations are Compact and/or Require Complete Silence)

    • Features:

      • View up to four computers on the multiview preview screen at the press of a button
      • View and control any computer on the main video/monitor output of the unit
      • Supports USB keyboard and mouse
      • Features USB 2.0 ports to connect additional USB devices like printers, cameras, USB drives, etc.
      • On-screen display (OSD) makes setup and switching easy
      • Change views by pressing the tact switches, keyboard hotkeys, and via RS-232 commands
      • Display each computer in clean and crisp high resolution video
      • Supports DP resolutions of up to 3840 x 2160 @ 30Hz
      • Quad-mode splits the preview screen to show all 4 computers simultaneously
      • Dual-mode splits the preview screen to show two computers at the same time
      • PiP-mode displays one computer in full screen with three thumbnail views
      • User-defined frame rate for each input

    • Specifications:

      • Video
      • Resolution HDTV: 720i, 720p, 1080i, 1080p, 2K, 4K
      • PC Resolution: 800 x 600 up to 3840 x 2160
      • Input Video Signal: 1.2 volts
      • Input DDC Signal: 5 volts
      • Format: DP
      • HDCP Compliance: 1.0/2.0
      • Input Interface: (4) DP
      • Output Interface: DP
      • Connector: Type A [19-pin female]

        USB
      • Input: USB 2.0, 1.1, and 1.0
      • Input Interface: (4) USB Type B
      • Keyboard: USB 1.0 (Type A)
      • Mouse: USB 1.0 (Type A)

        Control
      • Front Panel: Tact Switches
      • RS-232: DB9 (female)

        Other
      • Power: External 100-240 VAC/12VDC3A @ 36W
      • Dimensions: 12.57" W x 1.76" H x 6.69" D
      • Weight: 4.2 lbs
      • Approvals: UL, CE, ROHS Compliant
      • Operating Temperature: +32 to +104°F (0 to +40°C)
      • Storage Temperature: -4 to 140°F (-20 to +60°C)
      • Humidity: Up to 80% (No Condensation)

    • Item Includes:

      • 1x 4-Port DisplayPort, USB 2.0 KVM Switch with Multiview Preview Screen and Audio Support.
      • 1x PS12VDC3A 12V DC, 3A (minimum) power adapter with center-pin positive polarity

    • Warranty:

      • 1 year
