SmartAVI SA-DPN-8S-P 8-Port SH Secure Pro DisplayPort KVM with Audio and CAC

ITEM #: SAVI-SA-DPN-8S-P MFG #: SA-DPN-8S-P

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Smart-AVI
Free Shipping with $49 Minimum Order

Our Price:

$2,420.00

Add to Wish ListLeasing Options
Availability: 2+ Weeks.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

SA-DPN-8S-P - Overview

SmartAVI SA-DPN-8S-P is an 8-Port SH Secure Pro DP KVM with Audio and CAC. This supports Windows, Mac and Linux OS with advanced configurable CAC port and an External power supply with Level VI efficiency. No external interfaces can be used, only keyboard, mouse and CAC devices are accepted. You can ensure that all user data is completely isolated and no data is ever stored, as well as secure channel switching with leak prevention and no hotkeys.

  • Features:

    • Computer interface isolation while powered or unpowered
    • Front panel tactile buttons for secure channel switching and LED channel indicators
    • Peripheral and authentication ports isolation for secure usage
    • Tamper evident label and anti-tampering technology
    • No wireless devices connected
    • Ensures only trusted admin gains access


  • Specifications:

    • Video
    • Format: DisplayPort1.2a
    • Input Interface: (16) DisplayPort
    • Output Interface: (2) DisplayPort
    • Resolution: Up to 4K (3840x2160 @ 30Hz)
    • DDC: 5 volts p-p (TTL)
    • Input Equalization: Automatic
    • Input Cable Length: Up to 20 ft.
    • Output Cable Length: Up to 20 ft.

      USB
    • Input Interface: (16) USB Type B
    • Output Interface: (2) USB 1.1 Type A for KM Devices
    • Emulation: USB 1.1 and USB 2.0 Compatible
    • CAC: Configurable USB 2.0 Port

      Audio
    • Audio Input: (8) 3.5mm stereo audio
    • Audio Output: (1) 3.5mm stereo audio

      Control
    • Front Panel: Front panel SELECT buttons

      Other
    • Power: External 100-240 VAC/ 12VDC3A @ 24W
    • Dimensions (WxHxD): 17 x 1.76 x 8.69"
    • Weight: 6.3Lbs
    • Approvals: NIAP PP 4.0, UL, CE, ROHS Compliant
    • Operating Temperature: 32° to 104°F (0° to 40°C)
    • Storage Temperature: -4° to 140°F (-20° to 60°C)
    • Humidity: Up to 80% (non-condensing)


  • Warranty:

    • 1 Year


  • GTIN:

    0686911124228
