Fiberplex SFX-SC92DT-3100A SFX Series 10-Gigabit Cyber-SFP Data Diode Module for Air Gap Networks - Singlemode/LC - TX

ITEM #: SFX-SC92DT-3100A MFG #: SFX-SC92DT-3100A

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$1,008.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


SFX-SC92DT-3100A - Overview

One-Way Traffic Protection for Your IT Network!

When government and defense IT professionals are looking for a bona fide, yet simple, security product, they turn to the FiberPlex SFX-SC92DT-3100A Data Diode. These simple plug and play SFPs feature a data diode functionality, which means data only transmits in one direction without the possibility for a return path, while offering outstanding 10-gigabit optic performance.

The SFX-DD modules are high performance, cyber secure modules supporting a host of data rates and distances. Patton's FiberPlex Cyber-SFP Modules are compatible with the small form-factor pluggable (SFP) multisource agreement (MSA). They are RoHS compliant and lead-free.

Applications Include:
Network Security and Segmentation
Data Availability
Bilateral/Bidirectional Transfers

  • Features:

    • Single LC connector
    • Single direction with no possibility for a return path
    • Hot-pluggable SFP footprint
    • RoHS compliant and Lead Free
    • Milled Brass enclosure for maximum EMI/RFI containment and durability
    • Single +3.3V power supply
    • Low power dissipation <800mW
    • SFP MSA SFF-8074i Compliant.
    • Designed and Manufactured in the USA: Top notch quality and reliability with local support
    • Perfect for use in Air Gap Networks where cyber security is paramount

  • Specifications:

    • Storage Temperature: 0 to 185°F (0 to -40°C)
    • Voltage Range: 3.13-3.47 VDC
    • Supply Current: 250mA
    • Dimensions (LxWxH): 2.2 x 0.54 x 0.47" (56.5 x 13.7 x 12mm)
    • Weight: 0.05lb (22.7g)

  • Item Includes:

    • FiberPlex SFX-10DD 10 Gigabit SFP data diode module for Cyber Security - TX


SFX-SC92DT-3100A - Required Accessories
