SKB 1SKB-R104 Roto Rack 10U Top & 4U Front Rack Console

1SKB-R104 - Overview

• Features:

  • 10U Slanted rackmount on top
  • 4U rackmount in front
  • Room for cables
  • Hard lid and doors
  • Side access ports for cable routing
  • Injection molded front and rear doors and lid
  • Two TSA locking patented trigger latches
  • Stackable for storage and transport


• Specifications:

  • Exterior Length 23.25 in 59.06 cm
  • Exterior Width 23.50 in 59.69 cm
  • Exterior Depth 17.75 in 45.09 cm
  • Rack Space Units Top 10
  • Rack Space Units Bottom 4
  • Rack Depth Rail to Rail 6.00 in 15.24 cm
  • Rack Depth Front Rail to Back Lid 19.50 in 49.53 cm
  • Shipping Weight 28.00 lb 12.70 kg
  • Product Weight 24.00 lb 10.89 kg
  • Rack depth is listed at 6" and that is referencing the top of the rail on the slant portion of the case. At the bottom of the rail, the depth is 3.75". If nothing is mounted in the 4 spaces on the front, then the actual depth at top of the slant rail would actually be 13.5". After the first 3" from the bottom of the slant rail (and with nothing mounted in the 4 spaces on the front), the depth is 11.75". Space between the top of the slant rails and the cover is ~3.5" (to allow XLR/cable connections on mixer with top mounted mic pres). Product weight is without the optional 1SKB-AV8. The 1SKB-AV8 weighs 6 pounds.


• GTIN:

  0789270010406
