S-3812A can charge 2 Gold mount batteries simultaneously at Max 6A fast charging current, to SWIT particular batteries. The charging speed is quite faster than normal chargers. The following battery models support 6A fast charging: S-8340A, S-8360A, D-8161A And for other batteries, the charging current is 3A.
AC-DC Adapting Output
S-3812A supports 1-ch AC-DC adapting output via 4-pin XLR port. By S-7102 (4-pin XLR female to male) cable, it can supply 16.8V DC power to the other equipments, Max load 200W/12A. When adapting load is less than 100W, S-3812A can still charge battery simultaneously. (2 batteries sequential).
Battery-DC Adapting Output
You can also mount batteries onto S-3812A, and output DC power via 4-pin XLR port. By S-7102 (4-pin XLR female to male) cable, it can supply 16.8V DC power to the other equipments, Max load 200W/12A.
