Techflex PTN1.00 1-Inch Flexo PET Expandable Tubing - Black - 250-Foot

ITEM #: TFX-PTN10-250 MFG #: PTN1.00BK 250FT

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$124.00

Our Price:

$95.70

Availability: In Stock
iAvailability Description Popup


PTN1.00BK 250FT - Overview

The FLEXO PET (PT) grade is used in electronics, automotive, marine and industrial wire harnessing applications where cost efficiency and durability are critical. The wide range of available colors and sizes allows easy and systematic color coding in complex wiring and cabling schemes.

The unique braided construction and wide expandability allows quick and easy installation over large connectors and long runs. PT can be found in applications ranging from small office/home office to high tech wire and cable harnesses.

PT is braided from 10 mil polyethylene terepthalate (PET) monofilament yarns. The material has a wide operating temperature range, is resistant to chemical degradation, UV radiation, and abrasion. The sleeving cuts easily and cleanly with a hot knife and once installed, will beautify and protect any wire, hose or cable application.

  • Features:

    • Economical and Easy to Install
    • Cut and Abrasion Resistant
    • Expands up to 150%
    • Halogen Free
    • Resists Gasoline, Engine Chemicals, & Cleaning Solvents
    • FMVSS 302 Approved

  • Specifications:

    • Physical Properties
    • Monofilament Thickness (ASTM D-204): .010
    • Flammability Rating: UL-94
    • Recommended Cutting: Hot Knife
    • Wall Thickness: .025
    • Tensile Strength - Yarn (ASTM D-2265) lbs.: 7.5
    • Abrasion Resistance: Medium
    • Specific Gravity: 1.38
    • Moisture Absorption % (ASTM D-570): .1 - .2
    • Nominal Size: 1"
    • Epansion Range: Min.: 5/8"; Max.: 1 5/8"

      Hard Vacuum Data (ASTM E-595 at 10-5 torr)
    • TML: .19
    • CVCM: .00
    • WVR: .16
    • Smoke D-Max (ASTM E-662): 56
    • Outgassing: Medium
    • Oxygen Index (ASTM D-2863): 21

      Operating Temperatures
    • Minimum Continuous: -94° F
    • Maximum Continuous (MIL-I-23053): 257° F
    • Melt (ASTM D-2117): 482° F

      Other Information
    • Halogen Free: Yes
    • RoHS: Yes
    • SVHC: None
    • UL/CSA: Yes

  • Item Includes:

    • 1x Expandable Braided Sleeving - 250 Feet - Black
