ADDERLink X-DVIPRO-DL-US USB2.0 & Dual Link DVI KVMA Extender TX/RX - 164 feet/50 Meters

X-DVIPRO-DL-US - Overview

• Features:

  • Dual Link resolutions for pixel perfect digital video with real time control: using uncompressed video extension; no visible artefacts or latency are introduced allowing you to be certain of quality and control
  • Distribution up to 164 feet/50m over a single CATx cable: video, USB 2.0 (Low and Full speed) and audio all pass along a single cable, providing up to 50m of extension with resolutions up to 2560x1600@60Hz (distance dependent upon video resolution, CATx cable type, and number of connection intervals)
  • Connect any USB interface device: utilizing a unique method of USB communication, the ADDERLink X-DVIPRO extenders deliver the highest possible levels of USB compatibility. All USB 1.1 and 2.0 low/full speed devices are supported.
  • HDMI video and audio extension capabilities: Digital audio for 8 channels of HDMI audio, supported simultaneously to analog audio


• Specifications:

  • Audio
  • The system delivers analog stereo audio (Line Out). 8 channels of HDMI audio are supported with sample sizes of 16, 20 or 24bits at 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, or 192kHz (simultaneously with the jack audio).


  • Approvals / Compliance
  • CE
  • FCC


  • Standards
  • DVI-D Interface - digital only the system supports resolutions to a maximum of 2560x1600 @60Hz.
  • Hardware compatibility: All computers with DVI-D, USB and audio - requirement dependent.


  • Cable Guidelines
  • Recommended cables are CAT7 shielded foiled twisted pairs:
  • Daetwyler 7702 Flexible patch cable
  • Daetwyler 7120 Bulk cable
  • Please Note: CAT5 (or better) shielded twisted pair cable must be used to connect the local and remote units in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. Distances are achieved using single lengths of trunk/bulk cable. For each break/patch connection reduce distance by 5m. Preferably patch cables should be of type CAT7a and less than 2m. Patch cables over 2m must be CAT7a. The maximum extension distance for USB is 50m including connections to and from the X-DVI PRO DL independent of cable type. If a USB hub is connected to the RX unit, this is seen as 5m of cable length. This needs to be taken into consideration when planning your system. CAT5e is not recommended for use with this system.


• Item Includes:

  • DVIPRO-DL local and remote modules
  • 2X 12.5W power supplies
  • 1x Dual link video cable DVI-D to DVI-D
  • 1x USB cable 2m (a to B)
  • 1x 3.5mm stereo audio cable


• Warranty:

  • 2 Year Limited


• GTIN:

  0641125319129
