Alpha Wire F2211/8 BK002 1/8 Inch Heat Shrink Tubing - Black - 500 Foot

ITEM #: ALPH-F22118BK002 MFG #: F2211/8 BK002

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$288.00

Our Price:

$273.43

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


F2211/8 BK002 - Overview

The F2211/8 BK002 FIT heat-shrink tubing offers a reliable way to protect and seal terminations or add additional mechanical ruggedness. FIT preferred heatshrink products are made from premium compounds under the tightest manufacturing controls. This means FIT will consistently have excellent physical characteristics such as low longitudinal shrinkage and wide temperature ranges while providing an elegant appearance when used alone or on OEM equipment.

  • Specifications:

    • Construction
    • Tubing Type: Heat Shrinkable Tubing
    • Tubing Material: Cross Linked Polyolefin
    • Minimum Supplied ID(In): 0.125
    • Maximum Recovered ID (In): 0.062
    • Nominal Recovered Wall Thickness(In): 0.020
    • Color: Black

      Physical
    • Temperature Range: -55 to 135°C
    • Shrink Ratio: Approximately 2:1
    • Full Recovery Temperature: 121°C
    • Minimum Shrink Temperature: 90°C
    • Tensile Strength: 1500psi, Min; ASTM D638
    • Elongation: 200%, Min; ASTM D638
    • Low Temperature Flex(-55°C): no cracking; AMS-DTL-23053
    • Heat Shock(250°C, 4hrs): no cracking; AMS-DTL-23053
    • Secant Modulus: 2.5x10 4 psi, Min; ASTM D882
    • Longitudinal Change: +/-5%; AMS-DTL-23053
    • Specific Gravity: 1.35, Max; ASTM D792
    • Shelf Life: 5 Years @ 18 to 35°C

      Electrical
    • Dielectric Strength: 500 V/mil, Min; ASTM D876
    • Volume Resistivity: 1x10 14 ohm-cm, Min; ASTM D876

      Chemical
    • Water Absorption: 0.50%, Max: ASTM D570
    • Corrosion(0°C,16hrs): no corrosion: AMS-DTL-23053
    • Fluid Resistance(23°C,24 Hrs): 1000 PSI, Min; AMS-DTL-23053
    • Fungus Resistance: Pass; AMS-DTL-23053
    • Vacuum Outgassing - CVCM: 0.10%, Max; ASTM E595

      Other
    • UL: Standard 224 (Except Clear) 600V
    • CSA International: Standard 198 (Except Clear) 600V
    • Other: AMS-DTL-23053/5 Class 1 (Except Clear)
