AV Pro Edge AC-DAC-CO2 2-Channel Digital to Analog Audio Converter - HDTV Digital Output Conversion - Toslink / Coax

AC-DAC-CO2 - Overview

• Features:

  • HDTV Digital Output Conversion
  • 24-Bit Conversion
  • Supports S/PDIF audio at 192kHz/24-bit data for conversion to left and right analog channels
  • Integrated digital interpolator filter and Digital-to-Analog Converter (DAC)


• Specifications:

  • Input Ports:
    - 1x TOSLINK (S/PDIF Audio)
    - 1x RCA (S/PDIF Audio)
  • Output Ports: 2x RCA (Stereo Audio)
  • Input Audio Format: LPCM 2.0
  • Output Audio Format: Analog 2.0
  • Input Sampling Rates: 32kHz, 44.1kHz, 48k Hz, 88.2kHz, 96kHz, 176.4kHz &192kHz
  • Output Level: 2Vrms
  • Output Impedance: 600ω
  • ESD Protection - Human Body Model:
    - ±12kV (Air Discharge)
    - ±8kV (Contact Discharge)
  • Weight: 0.07 lbs (30g)
  • Chassis Material: Plastic
  • Operating Temperature: 32°F - 104°F (0°C - 40°C)
  • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
  • Relative Humidity: 20% - 90% RH (Non-condensing)
  • Power Supply: 5V/1A DC (US/EU standards, CE/FCC/UL certified)
  • Power Consumption: 0.74W


• Item Includes:

  • 1x Digital to Analog Audio Converter
  • 1x 5V/1A DC Power Adapter


• Warranty:

  • 10 Year Warranty


• GTIN:

  0850015330643
