AVP KM75 Normalled / Non-Terminating Front Mount SuperHD+ Micro Video Jack

ITEM #: AVP-KM75 MFG #: AVP-KM75

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
AVP
Free Shipping with $49 Minimum Order

List Price:

$69.86

Our Price:

$57.23

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    AVP-KM75 - Overview

    AVP KM75 is a SuperHD Micro 3G Dual Video Jacks with Normaled Terminating.

    • Specifications:

      • Electrical
      • Rated Bandwidth: 3.0GHz - 3Gb/s: meets HDTV SMPTE 424M-2006 Specification
      • Characteristic Impedance: 75 Ohms
      • Contact Resistance: Less than 50 milliohms
      • Termination Resistance: 75 Ohm

        Environmental
      • Operating Temperature: -40°C to 65°C
      • Storage Temperature: -40°C to 65°C
      • Thermal Shock: Per MIL-STD-202, Method 107
      • Moisture and Humidity: Per MIL-STD-202, Method 106
      • RoHS: RoHS Compliant

        Mechanical
      • Mechanical Shock: Per MIL-STD-202, Method 213, Test condition I
      • Vibration: Per MIL-STD-202, Method 201
      • Life cycle: 20,000 minimum

        Material
      • Housing: Zinc alloy, nickel plated
      • Center Contacts: Copper alloy, gold plated
      • Switching Contacts: Copper alloy, gold plated
      • Grounding Contacts: Copper alloy, gold plated
      • Actuators: Thermoplastic, UL 94V-0 rated
      • Insulators: Teflon


    • Item Includes:

      • 1x AVP KM75 Normalled / Non-Terminating Front Mount SuperHD+ Micro Video Jack
