BZBGEAR BG-EXHKVM-70C 4K UHD HDMI and KVM Extender with Zero Latency up to 230 Feet - Supports HDR and ARC

ITEM #: BG-EXHKVM-70C MFG #: BG-EXHKVM-70C

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$149.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


BG-EXHKVM-70C - Overview

With a new IPCOLOR technology (a global leading and innovative protocol for UHD video digital transmission with lossless compression) the BZBGEAR BG-EXHKVM-70C extender is capable of transmitting HDMI and USB signals with zero latency (gamers loved it) across distances of up to 70 meters (230 ft) over a single Cat6/6a/7 cable.If your computer makes uncomfortable level of noise and you want to send it away to the basement and work peacefully in your office, or if your company policies require your workstation to be locked in server room - these are exactly why KVM extender was created. When you need to separate your PC and your Display/Keyboard & Mouse for a long distance this device will serve you well.You can use USB connectors on the receiver not only for your mouse and keyboard, but also for other USB 2.0 devices like storage drives. S/PDIF connector on the receiver will de-embed audio signal from HDMI, so you can connect your local audio system. BG-EXHKVM-70C supports resolutions up to 4K 60fps HDR10 as well as many audio formats like LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH. Aluminum housing and integrated surge protection provides more durability for your setup.

  • Features:

    • Stunning Image Quality Supports resolutions up to 4K@60Hz
    • Audio Extraction Digital audio can be extracted via the optical audio port
    • KVM Remotely control a PC from the display side with a keyboard and mouse
    • Plug and Play Easy setup, no drivers to install
    • HDMI Loop-Out Connect an additional display to the transmitter
    • Surge Protection Integrated surge protection increases reliability
    • Supports HDMI 2.0a, compatible with HDCP 2.2 and HDCP 1.4 Supports auto down-scaling to match display resolution Supports uncompressed 4K@60Hz 4:4:4 with HDR10 and zero latency

  • Specifications:

    • Technical
    • Transmitter Inputs:
      - 1x HDMI IN
      - 1x DC2.1
      - 1x USB-A
    • Receiver Inputs:
      - 1x DC2.1
      - 1x RJ45
      - 2x USB-A
    • Transmitter Outputs:
      - 1x HDMI OUT
      - 1x RJ45
    • Receiver Outputs:
      - 1x HDMI OUT
      - 1x S/PDIF OUT
    • HDMI Compliance: HDMI 2.0, compatible HDMI 1.4
    • HDCP Compliance: HDCP 2.2, compatible HDCP 1.4
    • Transmission Medium: CAT6/CAT6A/CAT7
    • Transmission Distance: =70 meters
    • Video Bandwidth: 18 Gbps
    • Video Support: 1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600, 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz, 3840x2160@24/25/30/50/60Hz, 4096x2160@24/25Hz
    • Audio Formats: LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH
    • Input TMDS Signal: 0.7~1.2Vp-p
    • Input DDC Signal: 5Vp-p
    • HDMI Connector: Type A 19 Pins, Female
    • Network Cable Standard: CAT6/CAT6A/CAT7, follow IEEE-5688 standard

      Mechanical
    • Weight:
      - Transmitter: 0.57lbs (260g)
      - Receiver: 0.57lbs (260g)
    • Power Supply:
      - Transmitter: 5V/2A
      - Receiver: 5V/2A
    • Power Consumption:
      - Transmitter: 4W
      - Receiver: 4W
    • Material: Aluminium alloy material & crystal panel
    • Dimensions (LxWxH):
      - Transmitter: 5.9" x 4.2" x 1.1" (150mm x 107mm x 28.4mm)
      - Receiver: 5.9" x 4.2" x 1.1" (150mm x 107mm x 28.4mm)
    • Operation Temperaure: -4°F - 140°F (-20°C - 60°C)
    • Storage Temperature: -22°F - 158°F (-30°C - 70°C)
    • Relative Humidity: 0% - 90% (no condensation)

  • Item Includes:

    • 1x HDMI Extender Transmitter
    • 1x HDMI Extender Receiver
    • 1x User Manual
    • 1x USB Cable
    • 2x 5V2A DC Power Supply
    • 8x Mounting Brackets
    • 18x Screws

  • Warranty:

    • 3 Year Limited Warranty

  • GTIN:

    0850023208347
