The Blackmagic Camera Fiber Converter lets you extend and power your URSA Broadcast from up to 2 km away using industry standard SMPTE fiber cables. It also includes common live camera controls with multiple channels of talkback and standard television industry talkback headset connections. The Blackmagic Camera Fiber Converter features 1 Ultra HD camera feed, plus 3 HD return feeds in a compact IP video based design.
The Blackmagic Camera Fiber Converter attaches to the back of URSA Mini and URSA Broadcast cameras and converts all of the video and audio connections, along with camera control, PTZ, talkback, tally and power into the SMPTE hybrid electrical and fiber optic cable. The cable used between the camera and studio converters is a standard SMPTE 311M hybrid electrical and fiber optic cable with a standard SMPTE 304 connector on each end. The cable features a 2 way fiber pair, data pair and power pair, along with a central strength member that gives it the needed durability for continuous use.
The Blackmagic Studio Fiber Converter provides an industry standard 200 volts of power to the camera converter for both the camera and its accessories. The converters at each end have dedicated micro controllers that continuously monitor power and will instantly cut it if a leak is detected. High voltages to the SMPTE cable are not enabled until the converters ensure that all safety checks have been completed. This means Blackmagic Studio Fiber Converter and Blackmagic Camera Fiber Converter are compliant with SMPTE fiber standards, making them incredibly safe to operate. At the camera end, power is stepped down and made available to the camera and accessories via standard 12 volt connections.
Please Note! BStock unit is Refurbished, Out of Warranty and No Visual Damage
