    CINEURSAA17K65 - Overview

    The Blackmagic Design URSA Cine 17K 65 is a revolutionary new digital film camera that introduces new advanced technologies with total integration into the post production workflow. This new model includes a new large format 65mm format RGBW 17520 x 8040 sensor with larger photo-sites for 16 stops of dynamic range, interchangeable PL, LPL and Hasselblad lens mounts, and industry standard Lemo and Fischer connections. The Blackmagic Design URSA Cine 17K 65 comes with 8TB of high performance storage built in and also includes high speed networking for media upload and syncing to the Blackmagic Design Cloud.

    URSA Cine features a revolutionary new sensor designed for incredible quality images at all resolutions from 4K to a massive 17K. The larger sensor builds on the technology of URSA Mini Pro 12K with larger photo-sites leading to an astounding 16 stops of dynamic range. The unique RGBW architecture provides equal amounts of red, green and blue pixels. This means it is optimized to deliver incredibly rich colors at all resolutions and provide the ultimate in image quality and flexibility.

    URSA Cine is designed to meet the demands of any high end production. The evenly weighted camera body is built with a robust magnesium alloy chassis and lightweight carbon fiber polycarbonate composite skin to help customers move quickly on set. Standard Lemo and Fischer connectors let customers control the camera remotely while providing power for lens motors and other accessories. Customers also get 12G-SDI out, 10G Ethernet, USB-C, XLR audio and more.

    Different projects require different lenses which is why URSA Cine features an interchangeable lens mount. Customers can quickly switch between PL, LPL, EF and Hasselblad mounts. Plus, each mount has contact pins to read lens metadata for monitoring and for use in post production.

    • Features:

      • Cinematic ultra large format 2.2:1 aspect sensor with a massive 16 stops of dynamic range.
      • Lightweight, robust camera body with industry standard connections.
      • Blackmagic RAW for real time 17K editing.
      • Generation 5 Color Science with new film curve.
      • High performance OLPF for reduced moire and aliasing.
      • High performance Blackmagic Media Module 8TB for recording included.
      • Recording media compatible with the Blackmagic Media Dock.
      • High speed wifi, 10G Ethernet or mobile data for network connections.
      • Built-in RTMP and SRT live streaming.
      • Optional Blackmagic URSA Cine EVF.
      • Includes DaVinci Resolve Studio for post production.

    • Specifications:

      • Camera Features
      • Effective Sensor Size: 35.64mm x 23.32mm
      • Lens Mount: PL mount. Interchangeable with URSA Cine lockable EF mount included
      • Lens Control: Lens control of compatible EF lenses. Lens data from compatible PL lenses and control of some PL lenses
      • Dynamic Range: 16 Stops
      • Resolutions: 12,288x8040, 12,288x6480, 12,288x6912, 12,288x5112, 9648x8040, 9408x6264, 8688x4896, 9312x4896, 9312x3864, 7680x6408, 8192x5360, 8192x4608, 8192x4320, 8192x3408, 6432x5360, 4096x2680, 4096x2304, 4096x2160, 4096x1704, 3216x2680
      • Frame Rates: Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported
      • High Speed Frame Rates: 12K 3:2 open gate up to 80 fps, 12K 17:9 up to 100 fps, 12K 2.4:1 up to 120 fps, 9K 3:2 Super 35 up to 100 fps, 8K / 4K 3:2 open gate up to 144 fps, 8K / 4K 2.4:1 up to 224 fps
      • Built in ND Filters: Button activated ND filters with clear, 2-stop, 4-stop and 6-stop IR ND
      • Focus: Focus button turns on peaking
      • Iris Control: Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode.
      • Screens: 2x Monitoring Screens, 1x Camera Status Screen, 1x Electronic Viewfinder
      • Monitoring Screen: 5 inch LCD capacitive touchscreen, 1920px x 1080px, 1500 nits
      • EVF Display: OLED Full 1920 x 1080 - 6.22 Million dots
      • EVF Diopter Range: -5 to +5
      • Tally: Live Tally Indicator on LCD, and URSA Cine EVF

        Connections
      • Total Video Outputs: 2
      • SDI Rates: 1.5G, 3G, 6G, 12G.
      • Analog Audio Inputs: 2x XLR analog switchable between mic, line and AES audio
      • Analog Audio Outputs: 1x 3.5mm headphone jack
      • Reference Inputs: Tri-Sync/Black Burst and Timecode
      • URSA Cine EVF: 1x USB-C with power, data, video and locking connector
      • Computer Interface: 2x USB Type-C side expansion ports for camera accessories
      • Ethernet: 1x 10Gb/s RJ-45 connector supporting 10/100/1000/10G BASE-T for Web Media Management, Blackmagic Cloud uploads, camera control and streaming
      • Timecode Clock: Highly accurate timecode clock. Less than 1 frame drift every 8hrs

        Audio
      • Mic: Integrated stereo mic
      • Built in Speaker: 1x mono speaker

        Standards
      • HD Video Standards: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
      • Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
      • SDI Compliance: SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1
      • SDI Audio Sampling: 48 kHz and 24 bit

        Media
      • Media: 1x Blackmagic Media Module
      • Media Format: Blackmagic

        Power Requirements
      • Power Supply: +24V DC external power supply 100-240AC 50/60Hz compatible with IEC C14 socket. Molex connector for rear battery plate.
      • External Power Input: 1x 8 pin socket. B-Mount battery plate.
      • Power Output: 1x 7-pin connector with +24V DC power output when camera is powered by +24V DC batteries or power supply. 1x 3-pin Fischer with +24V DC power output when camera is powered by +24V DC batteries or power supply. B-Mount battery plate including 2-pin connector with +12V regulated output from camera

    • Item Includes:

      • 1x URSA Cine 12K LF camera with PL lens mount
      • 1x Media Module 8TB
      • 1x URSA Cine Handle and bolts
      • 1x URSA Cine Top Rod Mount
      • 1x URSA Cine Baseplate 19
      • 1x URSA Cine Battery Plate B Mount
      • 1x URSA Cine Rubber Caps for connectors
      • 1x URSA Cine WiFi antennas
      • 1x URSA Cine Mount EF and mount screws
      • 1x URSA Cine 24V 250W power supply
      • 1x EF Body Cap
      • 1x PL Body Cap
      • 1x Plastic folding screen hood for 5" LCD
      • 1x DaVinci Resolve Studio with activation key
      • 1x Welcome wallet with QR code for software download
      • 1x Sticker
      • 1x Pelican 1510 Case with custom foam

    • GTIN:

      0933871600948
