Blackmagic Design CINEURSAMWC6KG2 URSA Broadcast G2 4K/6K Camera with Digital Film Sensor/Dual Gain ISO +36dB/H.265

ITEM #: BMD-URSABRDCSTG2 MFG #: CINEURSAMWC6KG2

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$4,195.00

Availability: In Stock
iAvailability Description Popup


CINEURSAMWC6KG2 - Overview

Blackmagic URSA Broadcast G2 is an incredibly powerful camera designed for both traditional and online broadcasters. The 3 cameras in 1 design allows it to work as a 4K production camera, a 4K studio camera or a 6K digital film camera! You can record to common SD cards, UHS-II cards, CFast 2.0 cards or external USB disks, using common file formats such as H.265, ProRes and Blackmagic RAW. You can even change the lens mount! No other broadcast camera is so flexible!

The large 6K sensor combined with Blackmagic generation 5 color science gives customers the same imaging technology used in digital film cameras. The 6K sensor features a resolution of 6144 x 3456 so it's flexible enough for broadcast and digital film work. When using B4 lenses, customers get a 4K window of the sensor for Ultra HD broadcast use. Changing to a PL or EF lens mount you can use the full 6K resolution of the sensor for digital film. With 13 stops of dynamic range, customers get darker blacks and brighter whites, so it's perfect for color correction.

URSA Broadcast features incredible low light performance so customers can shoot using ambient light or even under moonlight. The Blackmagic URSA Broadcast G2 features gain from -12dB (100 ISO) up to +36dB (25,600 ISO) so it's optimized to reduce grain and noise in images, while maintaining the full dynamic range of the sensor. The gain can be set via a camera switch, the LCD menu or remotely using the SDI remote camera control protocol.

The URSA Broadcast G2 features a B4 broadcast lens mount that includes optics specifically designed to match the camera's sensor. The B4 lens mount lets customers use modern Ultra HD lenses or lower cost HD lenses. Older HD lenses often feature resolutions well beyond HD, so customers get great quality at low cost. B4 lenses are fantastic because they are par-focal, so the image stays in focus as customers zoom in and out, so customers don't need to constantly chase focus as they shoot.

Note: All of the original accessories for the old URSA Broadcast and current URSA MINI models will work with the new G2 URSA Broadcast.

  • Features:

    • Native 6K sensor with 13 stops of dynamic range
    • Up to +36dB ISO for incredible low light performance
    • USB-C port allows recording directly to external disks
    • Includes Blackmagic generation 5 color science
    • Features incredible quality Blackmagic RAW recording
    • Optional focus and zoom demands for lens control
    • Compatible with new Blackmagic URSA Mini Recorder
    • Includes full DaVinci Resolve Studio for post production

  • Specifications:

    • Connections
    • SDI Video Inputs: 1
    • SDI Video Outputs: 1
    • SDI Monitor Outputs: 1
    • SDI Rates: 1.5G, 3G, 6G, 12G.
    • Analog Audio Inputs: 2xXLR switchable between mic, line and AES digital audio. Phantom power support
    • Analog Audio Outputs: 1x3.5mm headphone jack, supports iPhone style headset for talkback
    • Reference Inputs: Tri-Sync/Black Burst/Timecode
    • Lens Control: 1x12-pin Hirose Broadcast Lens Connector
    • Remote Control: 1x 2.5mm LANC input for Rec Start/Stop, plus Iris and Focus control using compatible lenses
    • Computer Interface: 1xUSB Type-C 3.1 Gen 2 with power delivery for external drive recording and connecting Blackmagic Focus and Zoom Demand. 1xUSB Type-C for software updates

      Audio
    • Mic: Integrated stereo mic
    • Built in Speaker: 1x mono speaker

      Standards
    • SD Video Standards: None
    • HD Video Standards: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60
    • Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
    • SDI Compliance: SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10
    • SDI Audio Sampling: 48 kHz and 24 bit

      Media
    • Media: 2x CFast 2.0 card slots, 2xSD UHS-II card slots, 1x USB-C 3.1 Gen 2 expansion port with power delivery for recording to external media
    • Media Format: Can format media to ExFAT for Windows and Mac or HFS+ for Mac (file systems)

      Codecs
    • Apple ProRes 422 HQ
    • Apple ProRes 422
    • H.265 SDI (10-bit 4:2:2)
    • H.265 High (10-bit 4:2:0)
    • H.265 Medium (10-bit 4:2:0)
    • H.265 Low (10-bit 4:2:0)
    • H.264 SDI (10-bit 4:2:2)
    • H.264 High (8-bit 4:2:0)
    • H.264 Medium (8-bit 4:2:0)
    • H.264 Low (8-bit 4:2:0)
    • Blackmagic RAW Constant Bitrate: 3:1, 5:1,8:1,12:1
    • Blackmagic RAW Constant Quality: Q0, Q1,Q3,Q5

      Talkback and Tally
    • Talkback: SDI Channels 15/16 and iPhone headset
    • Live Tally Indicator: Tally on LCD, URSA Viewfinder and URSA Studio Viewfinder

      Recording Formats
    • Apple ProRes 3840x2160 and 1920x1080 with film, video or extended video dynamic range or custom 3D LUT
    • H.265 3840x2160 & H.264 1920x1080 with film, video or extended video dynamic range or custom 3D LUT
    • Blackmagic RAW Q0, Q1, Q3, Q5, 3:1, 5:1, 8:1 and 12:1 at 6144x3456, 6144x2560, 5376x3024, 3728x3104, 3840x2160, 1920x1080 recorded in non-linear 12 bit with film dynamic range and extended video, video or custom 3D LUT embedded in metadata

      Power
    • Power Supply: 1xExternal 12V DC 100W power supply with 100 - 240V AC 50/60Hz IEC C14 input
    • External Power Input: 1x4-pin XLR port for external mains power supply or battery use. 1x12-pin Molex connector under rear battery plate
    • Power Output: +12V 4-pin XLR regulated output on side of camera, +12V D-Tap regulated output on VLock battery plate
    • Power: Rear mount compatible with standard V-mount or gold mount battery plates

      Environmental
    • Operating Temperature: 32° to 104°F
    • Storage Temperature: -4° to 113°F
    • Relative Humidity: 0% to 90% non-condensing

  • Item Includes:

    • 1x URSA Broadcast G2
    • 1x 4K B4 lens mount installed
    • 1x B4 turret dust cap
    • 1x EF Mount with dust cap
    • 1x VLock Battery Plate installed
    • 1x URSA 12V 100W power supply
    • 1x URSA Mini Shoulder Pad
    • 1x URSA Mini top handle & rubber stopper
    • 1x Viewfinder mounting plate
    • 2x 1/4 inch baseplate screws
    • 2x Long 1/4 inch top handle screws
    • 2x Short 1/4 inch top handle screws
    • 8x EF Mount screws
    • 4x VLock plate spare screws
    • 1x DaVinci Resolve Studio wallet
    • 1x DaVinci Resolve Studio activation key
    • 1x Software - Blackmagic OS, DaVinci Resolve Studio for Mac and Windows including activation key, Blackmagic Camera Setup, Blackmagic RAW Player, Blackmagic RAW QuickLook Plugin, Blackmagic RAW SDK, Blackmagic RAW Speed Test

  • Warranty:

    • 12 Month Limited

  • GTIN:

    9338716007435
