Chief ConnexSys Adjustable TV Wall Mount with Rails

LVS1UP - Overview

• Features:

  • Hang units on a single strut channel for quick row leveling
  • Reduces installation time - especially for XL and recessed configurations
  • Tool-free Click Connect latching secures displays
  • PowerZone provides 6 points of adjustment in one easy-to-access location at the top of the mount
  • 3 levels of lateral adjustment
  • Rapid Draw Display Release
  • Kickstand provides 20 degrees of bottom tilt access
  • Rigid frame keeps displays where you set them, even after extending for service
  • Adjustable home depth position locks screens in place to maintain alignment despite accidental bumps/pushes
  • Security - pad lock ¼" shank diameter
  • Safety tested
  • Universal interface
  • Each mount comes out of the box with adjustments set in the exact same position


• Specifications:

  • Certifications: UL Listed
  • Color: Black
  • Manual Height Adjustment: ± 1"
  • Maximum Extension: 13.4" (34.0 cm)
  • Minimum Depth: 4"
  • Mounting Pattern Compatibility (Universal Versions): 200 x 100 - 800 x 400 mm
  • Number Of Monitors: 1
  • Orientation: Portrait
  • Overall Dimensions (H x W x D): 32.5 x 19.5 x 4.1" (826 x 495 x 104 mm)
  • Shipping Weight: 42 lbs (19.05 kg)
  • Solution Type: Universal
  • Tilt: + 4.0°, -2.5°
  • Typical Screen Sizes: 40 - 80"
  • Weight Capacity: 150 lbs (68 kg)


• Warranty:

  • 10 Years


• GTIN:

  0841872161167
