Tripp Lite B004-VUA2-K-R 2 Port KVM Switch (USB) Desktop with Audio & Cables

B004-VUA2-K-R - Overview

• Features:

  • Fast, easy switching via keyboard hot keys, push buttons or software
  • Plug-and-play setup - no software required
  • Hot-swap capability allows easy addition or removal of computers without powering down the switch or other computers
  • Speaker and microphone connections allow sharing of audio components between systems (standard 3.5 mm audio connections)
  • Independent audio switching allows you to listen to audio from one computer while switching to the other computer
  • Supports video resolutions up to 2048 x 1536 (standard 15-pin VGA connectors)
  • Supports Microsoft® IntelliMouse® and the scrolling wheel on most mice]
  • Compact design saves desk space
  • Does not require an AC adapter
  • Compatible with all major operating systems
  • Includes two, 6ft Cable Kits


• Specifications:

  • System Requirements
  • Console: VGA, SVGA or Multisync Monitor, USB Keyboard and USB Mouse
  • Computers: VGA, SVGA or Multisync Monitor Port and USB Port
  • Audio (Optional): Speakers with standard 3.5 mm Connectors and a computer with 3.5mm ports
  • Compatible with all major operating systems

    Input
  • Bus Powered: Yes

    User Interface, Alerts & Controls
  • LED Indicators: Green (Selected PC)

    Physical
  • Color: Black
  • Material of Construction: ABS
  • Shipping Dimensions (hwd / in.): 3.00 x 7.90 x 7.80
  • Shipping Weight (lbs.): 1.80
  • Unit Dimensions (hwd / in.): 1.3 x 4 x 2.6
  • Unit Packaging Type: Box
  • Unit Weight (lbs.): 0.22

    Environmental
  • Operating Temperature Range: 32 to 104 F (0 to 40 C)
  • Storage Temperature Range: -4 to 140 F (-20 to 60 C)
  • Relative Humidity: 0%-90% RH, Non-Condensing
  • BTUs: 1.7 BTU/Hr
  • Power Consumption (Watts): 0.5

    Communications
  • IP Remote Access: No

    Connections
  • Ports: 2
  • PC/Server Connections: USB; VGA
  • Side A - Connector 1: (2) HD15 (Female)
  • Side B - Connector 1: HD15 (Female)
  • Side B - Connector 2: (2) USB A (Female)
  • Side B - Connector 3: (2) 3.5MM (Female)
  • Computer Keyboard and Mouse Interface: PS/2
  • Computer Monitor Interface: VGA
  • Console Keyboard and Mouse Interface: USB
  • Console Monitor Interface: VGA
  • Connector Plating: Nickel

    Features & Specifications
  • Number of Users: 1
  • NIAP-Certified Secure: No
  • Port Selection: Pushbutton; Hotkey; Software
  • Max Supported Video Resolution: 2048 x 1536 @60Hz
  • USB Specification: USB 1.1 (up to 12 Mbps)
  • Audio Specification: Stereo Audio
  • Cat5 KVM Switch: No
  • Technology: USB; VGA/SVGA; Stereo Audio


• Item Includes:

  • 1x Compact 2-port USB KVM Switch with Audio
  • 2x 6ft USB KVM Cable Kits and (2) 6ft 3.5mm Audio Cable Kits
  • 1x CD-ROM with KVM Switcher Software
  • 1x Owner's Manual with Warranty Information


• GTIN:

  0037332140043
