Chief Suspended Ceiling Projector System - Black

SYSAUB - Overview

• Features:

  • System comes out of box in the order needed with mount and column preassembled
  • Adjustable ceiling plate allows placement above or below tile and accommodates inconsistent T-grids
  • Compatible with 2' x 2', 2' x 4', 60 x 60cm, & 62.5 x 62.5cm ceiling grids
  • Detachable electric plate for pre-wiring
  • Compatible with popular 2 gang adjustable mud rings
  • Tool-Free Microzone adjustment eliminates the need for set screws
  • Centris technology enables effortless fingertip positioning with new tool-free lockdown
  • Adjustable 0-12" column with dual inlay channels for high and low voltage cables
  • Q-Lock Quick Release Lever provides quick connect/disconnect of the projector for service and enhanced security with an integrated key and lock system
  • Improved universal interface for easier lock/unlock at projector connection


• Specifications:

  • Adjustments: Roll, Pitch, Yaw (3°, 10°, 360°)
  • Certifications: UL Listed
  • Color: Black
  • Extension: 0 - 12" ( 0 - 304.8 mm)
  • Overall Dimensions (H x W x D): 19.82" x 7.25" x 24.94" (503.5 x 184.2 x 633.6 mm)
  • Shipping Weight: 19.60 lbs (8.89 kg)
  • Solution Type: Universal
  • Weight Capacity: 35 lbs (15.9 kg)


• GTIN:

  0841872166186
