ClearLinks CFU-00101S RJ45 to SFP Fast Ethernet Media Converter

CFU-00101S - Overview

• Features:

  • 10/100Mbps RJ45 Port: Supports auto-negotiation for seamless bridging between different network speeds and devices, integrating them into a fast Ethernet fiber network.
  • High-Speed Bandwidth: Ideal for expanding Ethernet networks in large-scale workgroups requiring demanding performance.
  • SFP Module Compatibility: Works with both multi-mode and single-mode fiber through various SFP modules.
  • Extended Range: Capable of extending Ethernet connections up to 120km with a 155M SFP module.
  • Auto-Negotiation and Auto-MDI/MDI-X: Supports 10/100BASE-T standards, ensuring automatic speed and crossover adjustments.
  • LED Indicators: Easy-to-read LEDs provide clear device status monitoring.
  • Power Consumption: Efficient power usage at 5W with input support ranging from AC110 to 240V.
  • Comprehensive After-Sales Service: Includes up to three years of quality assurance and maintenance.


• Specifications:

  • Optical Ports: 1x 100Base-SFP
  • Copper Ports: 1x 10/100BaseT RJ45
  • Wavelength: 850 - 1310nm
  • Fiber Mode: Multi-mode/Single-mode
  • Input Power: 5V DC, 1A
  • Operating Temperature: 32°F - 122°F (0°C - 50°C)
  • Storage Temperature 14°F - 158°F (-10°C - 70°C)


• Item Includes:

  • 1x Power cord
  • 1x Warranty card
    Please Note: SFP modules required, sold separately.


• Warranty:

  • 3 Year Warranty
